c. BFR (BUFFER)/BLACK
d. M/E 1 - M/E 4 (or M/E 8)
(Press Shift with M/E 1-4 to access M/Es 5-8 when using a 460 CS
with an 8-input TriCaster)
Switcher row buttons are mutually exclusive, and the active selection button
remains lit.
Hint: Hold down CTRL when clicking a button on the Preview row to toggle LiveMatte on/off
for that source. Likewise, hold CTRL + SHIFT while pushing a Preview row button to toggle
its Proc Amp. Note that the source need not be actually selected on the PREVIEW row to
do this, and multi-selections are supported.
UTIL row buttons are also mutually exclusive. The subordinate role of the UTIL Row
is subtly reinforced by the use of slightly smaller buttons. Source options include:
1. 1 – (4 or 8); Camera inputs
2. NET 1 and NET 2
3. Media Players:
a. DDR 1 and DDR 2
b. Graphics 1/2
c. BFR (BUFFER)/BLACK
Press CTRL + (UTIL row button) to access extended source options for the AUX Out
delegate only:
d. [CTRL + 1] – [CTRL + (4 or 8] → select BFR 1- (4 or 8)
e. [CTRL + NET 1] → select Preview
f.
[CTRL + NET 2] → select Program
g. [CTRL + DDR 1] → select Program (Clean)
FIGURE 347
Page | 374
UTIL (U
) R
TILITY
UTIL B
D
US
ELEGATE
UTIL BUS DELEGATE (Figure 347) button selections
govern which switcher layers the UTIL row is currently
OW
