In turn, this combined stream resolves into 3D when viewed through special glasses
with red and cyan (blue-green) filters for left and right eyes respectively.
TriCaster provide easy access to anaglyphic technology by means of the Anaglyph
effect. The effect combines 2 video inputs selected in an M/E. 3D output can then be
switched easily like any other source. No complex configuration steps or tricky
control surface operations are required.
The effects in the Photoshop Blend folder apply well-known
blending modes to the A layer in the M/E as these are blend with
the B layer.
The resulting compositions can serve many purposes, such as
adding animated 'bokeh' style overlays using DDR clips or adding
interest to still overlays such as vignettes or titles.
FIGURE 235
We've considered TriCaster's Default and Utility effects. Let's move on to a more
glamorous species, the virtual set, presented in TriCaster as LiveSet™ effects.
FIGURE 236
P
HOTOSHOP
14.2.5 VIRTUAL SETS
FIGURE 237
B
LEND
Page | 243
