22.6.10 PRESET (DDR PLAYLIST)
"P" is for "preset" ... or "playlist", if you prefer.
However you choose to view it, the buttons labeled P1
– P4 allow you to quickly access any of the first four
playlist presets for the currently selected DDR.
TW-42 N
Preset selection is not supported by TW-42.
OTES
22.6.11 TRANSPORT (CLIP CONTROLS)
FIGURE 372
The Jog Wheel is supplemented by the nearby Fast Jog button. Press this control to
toggle a high-speed jog mode, which skims through the clip at eight times the normal
rate.
TW-42 N
The Jog wheel on TW-42 works similarly, but is augmented by an outer
OTES
Shuttle ring that can be used to move quickly through a clip or playlist.
The other buttons in this control group are labeled with familiar VCR-style icons, and
work as follows:
Page | 402
This group of controls provides a variety of
convenient clip transport and navigation tools. The
dominant feature is a large, smoothly operating Jog
Wheel.
This oversize knob permits you to traverse the current
clip in the delegated DDR in frame-accurate
increments.
The Jog Wheel can be a real boon when coupled with
the ALT + IN/OUT method of trimming already
captured clips (Section 22.6.6), or can allow you to
review an event by scrubbing through it manually
even while it is displayed live.
FIGURE 371
