FIGURE 134
The Input Settings tab also contains Proc Amp (processing amplifier) settings. Input
Proc Amp adjustments are applied after LiveMatte is processed, which can help when
composing greenscreen shots to match a background or LiveSet.
You may also notice that changes to Proc Amp settings affect stopped (or frozen)
sources, including live camera feeds.
A switch at the top of the Proc Amp control group toggles the feature on/off. Other
controls operate as follows:

Brightness: Adjustment range from -50 to +50 IRE (the default being 0). As
reference, the full luminance range of the visible portion of a video signal can be
thought of as '100 IRE units' (named for the Institute of Radio Engineers) –
ignoring minor regional variations.

Contrast – Adjustment range
from 25 - 400% (default 100%).

Hue – Adjustment range between
-180° and +180°.
master color of the video signal
from the
swinging the
through the
spectrum.

Saturation – Adjustment range
from 0-500%.
results in a 'black and white'
picture; increased
results in richer colors.
saturation values can exaggerate
the color portion of the signal.
(Note that over-saturated colors
are considered
Page | 160
Adjusts the
attached source,
entire image
color wheel's
Zero saturation
saturation
High
illegal for
Proc Amp practices:
Whenever possible, it is best to
perform color adjustments at the
source or target
example, it is preferable to calibrate
a camera's colors at the camera,
before sending the signal to
TriCaster. Doing so will yield
higher color precision.
TriCaster's Proc amps are available
for occasions when no upstream
color correction is available.
broadcast
device. For
