SECTION 15.6 INTERNAL SOURCES
FIGURE 255
Besides external audio sources, sounds played from TriCaster's internal storage
volumes (including removable media such as external hard drives or 'thumb' drives)
via the Media Players (DDRs, etc.) can be added to the output mix.
15.6.1 NET 1 AND NET 2
The Net 1 and Net 2 audio control groups affect sound associated with the Switcher
sources by the same name.
Numerous network input sources, including NDI
(Network Device Interface™), iVGA PRO™, 3Play™, network feeds from another
TriCaster, and more may support embedded audio (see Chapter 16, Network Inputs).
15.6.2 MEDIA PLAYERS
Video and audio-only files in DDR 1 and 2 playlists along with audio files in the Sounds
player may contain one or more audio channels. At most, Media Players output the
first four audio channels of multiple channels – additional embedded channels are
ignored. Other options and controls in these sub-panels are similar to those provided
for external audio sources.
15.6.3 EFFECTS (TRANSITIONS)
This control group governs the sound embedded in Animation Store Transitions.
The remaining control groups in the Audio Mixer are dedicated to TriCaster's various
audio outputs. We'll come back to them in Section 15.8, but before we do so, let's drill
further down into more advanced audio options and tools.
Page | 257
