The Configuration panel for the Camera inputs features a Connection type menu at the
top of its Input Settings tab. Connection menu options vary depending on the Video
Standard for the session. TriCaster Multi-standard provides PAL and NTSC-J session
options, in addition to NTSC.
The Connection Type menu options for a PAL session list PAL HD and SD format
options. Choosing NTSC as the session Video Standard results in a Connection Type list
with appropriate formats, and it is similar for NTSC-J. Changing from one Video
Standard to another requires opening a new session.
Hint: All connected cameras must conform to the current Video Standard for the session.
The standard options are (note that TriCaster 410, Mini SDI and Mini do not support
analog video input options):
1080i (Component), 1080/30PsF (Component), 1080/24p
Telecine (Component)
• Analog source, high definition, interlaced or PsF (Progressive Segmented Frame)
2
• 1080/60i ,
• 1920x1080 pixels, 16:9 picture aspect
• Connected to TriCaster by Y, Pr and Pb input connectors
1080i (SDI)
• Digital source, high definition, interlaced
• 1080/60i or
• 1920x1080 pixels, 16:9 picture aspect
• Connected to TriCaster by SDI input connectors
• Optionally carries embedded audio
8.2.1 CONNECTION TYPE
1080/50i, or 1080/24p
2
1080/50i
Page | 155
