L
T
/A
OCAL
AKE
UTO
Local Take and Auto buttons are provided for DSK 1 and DSK 2, but not FTB. These
perform a cut or transition respectively, affecting only the corresponding switcher
layer.
Hint: When a DSK layer is fully displayed on Program out, its local Take button (on the Live
Desktop as well as the control surface) remains lit.
This section of the control surface corresponds to the tabbed M/E panes on the Live
Desktop. The M/E DELEGATE button group determines which M/E (from the four or
eight available) is being controlled.
FIGURE 350
In contrast with the Live Desktop, your TriCaster CS adjusts position attributes M/E
video layers using a single set of Positioner tools governed by Delegate controls (see
Section 22.4.7).
Your TriCaster CS provides an M/E DELEGATE button group to govern which M/E(s)
are affected by operations. Selected DELEGATE buttons are illuminated and,
conveniently, multiple selections are supported. When using a 460 CS with an 8-input
TriCaster, add SHIFT with a selection to delegate
F
PVW
OLLOW
Enabling the FOLLOW PVW button (M/E DELEGATE group) forces the DELEGATE
selection to track the Switcher's PVW row selection. This can be very valuable, as it
Page | 378
22.4.6 M/E GROUP
M/E D
ELEGATE
