The
INPUT/INSERTS
reassign the label for a slider input to a different TriCaster audio control by name, or
to insert (or remove) a new (initially unassigned) control column on the surface.
Controls for unused inputs or outputs can be removed from the surface, or if you wish,
you can re-order controls using the Remove and Insert features. To insert a new
control strip on the surface, proceed as follows
1.
Make sure
press the
INSERTS
2.
Rotate the knob for Input one clockwise, cycling
through optional settings until the label above the knob
says Insert.
At this point, the small
knob begins to flash, to indicate that if you wish to confirm
your selection you must press it (otherwise, press
to cancel the operation and revert to the original
selection).
3.
Press the
SEL
This action inserts a new, unassigned control, pushing the original Artist Mix
control group to the right to make room for the addition.
4.
Slowly rotate the same knob again – this time, you could choose an option
(such as Master 1 option), and then press
TriCaster's Input 1a (left) input channel. Instead, just select Remove this time
and press
Hint: Normally, if you insert a source that already appears elsewhere in the layout, the
inserted control group is kept and the original is removed.
By default, Artist Mix presents control groups for each TriCaster audio source in their
natural order from left to right. It can be very desirable however, to lock one or more
sources in a fixed position, thus keeping it in view on the control surface at all times
despite any use of the navigation buttons.
22.7.17 INSERT
button serves several important purposes. It can be used to
and
are both turned off, and then
FLIP
CHAN
button in the Knob Set group.
SEL
button to execute the insertion.
to confirm.
SEL
22.7.18 LOCKING CHANNELS
button just left of the rotary
once more to lock the input to
SEL
FIGURE 390
MIX/PAN
FIGURE 389
Page | 415
