TriCaster's latency is very minimal (as little as 1 frame), but you can take measures
to keep it to a minimum – first and foremost, by genlocking your video devices – see
Section 8.1.2. For genlocked sources, consider disabling TriCaster's Frame Sync – see
Section 8.2.3.
In a seemingly related matter, note that audio and video passing through TriCaster
are always synchronized. However, aspects of the physical design for IMAG (video
projection) installations can make mimic a sync issue for viewers at some locations
in the auditorium. These issues are discussed in detail in Section B.3, IMAG and
Latency.
S
Q
:
UPPLEMENTARY
UESTION
Q: Why does latency seem higher for certain video formats (i.e. 24p, 25p, or 30p)?
A: TriCaster passes frames through the switcher at the appropriate frame rate. When
the session format calls for frames at 60Hz, displayed frames are refreshed much
more often than (for example) a 24p format. Consequently, apparent latency will also
be less than half what it would be at 24Hz.
In general, the lower the frame-rate of the session video format, the higher latency
will seem to be.
A.8.2 WHY IS MY POWER SUPPLY BEEPING?
TriCaster 8-input systems provide redundant, replaceable power supply units. When
you i) disconnect or ii) power down just one of the modules, or iii), if a PSU should
fail, a beep is sounded to alert you. If you wish, you can mute the alert by pressing the
green button on the back of the unit.
Page | 464
