Note: Similarly, external projects will not be backed up by the Backup Session function (or
be deleted by the Delete Session function)
To create a new LiveText project, click in the default project name field (just above the
Start New Project link) and modify it, then click Start New Project.
When you finish working in LiveText, click the [x] button in its upper-right corner (or
select Exit in the File menu) to return to the Session Page.
5.3.3 MANAGE
FIGURE 107
Various TriCaster components provide filebins to permit you to manually administer
files related to their projects, playlists, and so on. The Manage icon in the Session Page
provides an alternative approach to file management.
At times you may find it useful to be able to quickly access the various files associated
with specific sessions. Selecting Manage refreshes the options pane on the right-hand
side of the Session Page with a number of convenient items.
B
ROWSE
Under the label Browse, you will see direct links to the Clips, Still, and other content
associated with the current session. Clicking one of these links (or selecting it with
the up/down arrow keys and pressing Enter) opens a system file explorer.
You can use the familiar features and shortcut keystrokes in these windows (Cut,
Copy, Paste, Rename, Delete and so-on) to manage the session content.
Page | 123
