8. Notice that you were able to edit a page without disturbing the title already
displayed on Program Output - Click the Close button.
9. Repeat your text edit operation but this time editing the title displayed on
Program Output.
Notice that, this time, the display updates immediately.
FIGURE 73
10. Try changing the Font, Size and other attributes for a line of text, using the
tools in the Title Page Editor's titlebar (Figure 73).
11. Click the Close button.
Let's try something different now – using LiveMatte to create a typical 'weather
report' shot.
(We'll use a pre-recorded sample clip for this task, but of course if you happen to have
a greenscreen studio ready to use, just skip the first three steps below, and select the
appropriate Input button on the Switcher's Program row - instead of a DDR).
1. Change the Switcher's Program row selection to M/E 1, and enable the BKGD
delegate button in the Transition section of the Switcher.
Page | 88
SECTION 4.10 LIVEMATTE & M/E
