Processing - NewTek TriCaster Mini User Manual

2. For Input 2, enable only Master 1.
This setup gives you a clean output consisting of just the interviewer's voice on the
Master 1 bus. You can then proceed as follows:
3. Assign Master to Output 1 in Output Configuration (Figure 261).
4. The Master 1 output connectors (1a and 1b) supply your primary audio
program output for distribution.
5. Connect TriCaster's connectors Master 2 *connectors (1c and 1d) to your
remote call hookup's local audio input to send the clean 'mix minus' back to
your interviewee.
*Note that on certain TriCaster models, Master 2 and Aux 2 signals are only
supplied to digital outputs.
This approach eliminates annoying echoing, feedback and the like. Meanwhile, both
participants can be heard on the main Program output. Also important, independent
control and signal processing is provided for each part of the pipeline.
The second tab in Audio Configuration is named Processing, and likewise holds very
valuable features.
The seven-band equalizer allows you to 'shape' sound to taste, accommodate sources
with different acoustic characteristics (say, mismatched mics), minimize feedback or
roll off unwanted parts of the audio spectrum.
Enable or disable the Equalizer using the switch beside the label above its control
group. The vertical sliders attenuate or boost the tonal range centered on the
frequency shown at the top.
Page | 264

15.7.5 PROCESSING

E
QUALIZER
