a. Move the mouse over the Program monitor, and double-click to open
Output Configuration.
b. Click the Output tab, and select either Composite + Y/C or Component
for Inputs 1-3 according to the connection type used by devices
connected to each output. (Please see Section 3.8 for more.)
A.1.6 CONNECT A SUPPORTED EXTERNAL CONTROL SURFACE?
Connect the USB cable from the Control Surface to one of TriCaster's USB ports.
S
Q
UPPLEMENTARY
UESTION
Q: The control surface has suddenly stopped working. What can I do?
A: The foremost reason this might happen is if the cable (or extender cable) you are
using between the control surface and the TriCaster failed to deliver sufficient current
consistently. In the short term (if you are in the middle of a show), you can generally
resolve this issue by simply unplugging and re-plugging the control surface.
However, please note that the use of so-called "USB extenders" is not recommended.
Whenever possible, use a single USB cable of the correct length. Each added connector
on the signal path is a potential connection problem, and also causes signal
'reflections'.
Such an arrangement may seem to work for a while, then fail
unpredictably.
If you are using a very long USB cable (or a poor quality cable), you should supply a
powered hub at the end of the cable nearest the control surface, then complete the
connection with a short USB cable from the hub to the control surface. (An unpowered
hub will be of no help.)
A.1.7 MIRROR CONTROL OPERATIONS TO ANOTHER TRICASTER?
1. Connect the second TriCaster to the same network.
2. Refer to Section 17.7.1 for details of preparing the two TriCasters and
enabling Remote Control.
Page | 428
:
