We know our products play vital roles in the productions of our customers. Durability
and consistent, robust performance are much more than just adjectives for your
business and ours.
For this reason, all NewTek products undergo rigorous reliability testing to ensure
they meet our exacting test standards. For TriCaster 8000, 860 and 460, the following
standards are applicable:
Test Parameter
Temperature
Ambient Operating
Ambient Non-Operating
Humidity
Ambient Operating
Ambient Non-Operating
Vibration
Sinusoidal
Random
Electrostatic Discharge
Air Discharge
Contact
F RELIABILITY TESTING
Evaluation Standard
Mil-Std-810F Part 2, Sections 501 & 502
0°C and +40°C
-10°C and +55°C
Mil-STD 810, IEC 60068-2-38
20% to 90%
20% to 95%
ASTM D3580-95; Mil-STD 810
Exceeds ASTM D3580-95 Paragraph 10.4: 3 Hz to 500 Hz
Mil-Std 810F Part 2.2.2, 60 minutes each axis,
Section 514.5 C-VII
IEC 61000-4-2
8K Volts
4K Volts
Page | 497
