FIGURE 27 (8-INPUT VERSION SHOWN)
Each input has its own small control panel, with Volume slider(s), VU meter(s), and
other important features conveniently located. At the top of each of these control
panels is a label. Roll the mouse pointer over the label to reveal a gear button at right
which, when clicked, opens the Configuration panel (Figure 28) for the input.
FIGURE 28
This panel holds advanced audio features as well as basic setup controls. After
connecting audio sources to the input connectors (see also Section 3.5.1), the first
thing to do is set the correct Connection Type using the drop-down menu:

Select Mic 1, 2 for professional grade microphones or similar sources. On
supporting models, use the Phantom option for condenser type microphones
requiring supplementary power.

Choose Line for most other device connections (including consumer devices
such as a CD player, computer audio output or VCR).

For 8-input models only, select AES/EBU for digital audio from an AES/EBU
(AES3) output.
Page | 44
FIGURE 29
A source Type selector drop-down at
the top of the Configuration panel
(Figure 29) lists the Connection Type
options available for the corresponding
input. Options may include Mic 1, 2
(with and without phantom power),
Line, AES/EBU, and SDI Embedded.
Note: TriCaster Mini omits this menu for
inputs that support HDMI audio only.
Likewise, Phantom power is not supported
by TriCaster Mini models.
