FIGURE 400
A.4.5 PREPARE CLIPS WITH EMBEDDED ALPHA CHANNEL?
Probably the best format to use for files with embedded alpha channel for use in
TriCaster are those encoded using NewTek's own SpeedHQ 4:2:2:4 codec. This
format can serve for either SD or HD clips, and represents a high quality, moderately
compressed alternative. (As a registered NewTek customer, you can download the
NewTek TriCaster Codec Pack for either Windows® or Mac® platforms from your
personal Downloads page on the NewTek website.)
Apple® computer users have several other options available which support an alpha
channel, including the Animation and PNG Quicktime® movie codecs (select "Millions
of Colors +" in the codec settings to include alpha in the file).
A.4.6 ADD AN EXTERNAL FILE LOCATION TO THE FILE BROWSER?
1. Open (or create) a TriCaster session.
2. Click the Add button for a Media Player (DDR, Still or Title).
3. Click the Add Media Location button at bottom left in the File Browser.
4. Select the folder you wish to list as a location in TriCaster's File Browser, and
click OK.
(See Add Media Location in Section 11.2.2)
Page | 450
