Hint: Although the GAIN control is shown for other source types, it really only has any
effect on inputs configured as Mic types in TriCaster's audio input source selector.
Push the small
ON
for Mic sources.
Two larger buttons labeled
positioned below the knob; that is, above each of the eight
faders (Figure 381). These two buttons are outside the
Knob Set group, and thus independent of the mode
established by the of Knob Set selectors.
That's just a wordy way of explaining how it is that a
always toggles the Solo feature for its respective source; and likewise the
buttons always mute or un-mute them – even when you might be in a different mode.
Hint: As with most convenient rules, there is one exception to the above. If the SOLO and
ON buttons are unresponsive, check to see if the
button on the control surface) is lit; if it is, turn it off.
At the time of writing, multi-selection of Solo is not supported on the Artist Mix
surface (though it can be performed in the TriCaster user interface).
Two other small buttons sit just to the left of each fader strip. These are labeled
and
AUTO/REC N
ASSIGN/SEL Y
(the default)
mode, but we are interested in the first –
PAN
. This button (with the earlier caveat about
N
toggles the Follow feature on and off for the designated TriCaster
audio source.
Having covered the basic control functions and settings, let's advance
to consider the tools available in different Knob Set modes.
22.7.10 TALK
button to the left of the knob to toggle the Talk (Talk Over) feature
22.7.11 SOLO & MUTE
SOLO
22.7.12 FOLLOW
. The latter is not normally relevant in
and
(Mute) are
ON
SOLO button
SHIFT LOCK
SHIFT LOCK
FIGURE 381
ON
button (i.e., the left
AUTO/REC
in mind)
FIGURE 382
Page | 411
(Mute)
