Several controls are nested above each fader, along with the matching OLED display
group for that audio input or source. Looking at Figure 379 you'll notice that in the
default operating mode (
shows a VU meter at left, and a PAN graph below the input label. Rotate the knob
below the PAN graph display to adjust PAN for the channel this
source is on.
For a four channel source, such as an input set to SDI Embedded,
TriCaster's level knobs each control two channels. An Artist Mix
knob set can likewise be configured to control "Audio1 AB" and
"Audio 1 CD" (for example) to control the two channel pairs for a
single SDI source (see Section 22.7.17 for details).
In such cases, the PAN control knob adjusts the first channel by
default (A, in this example) for the assigned pair.
To adjust PAN settings for the other channel in the same pair, press
the button (just below the OLED in the same Knob Set group).
SEL
This lights the button, and re-assigns the PAN control on the surface
to the associated channel. Press the
control over the first channel (the
To adjust MIC GAIN for a channel, press the CHAN button. Then push the button
labeled located to the left of the fader for the channel you want to control. The
SEL
highlight behind the source label in the OLED display updates to show the newly
selected source. In
right of the channel's PAN control on the surface.
These GAIN controls correspond to mic trim controls found in TriCaster's input Audio
Configuration panels (Audio Mixer tab). Press CHAN again to restore normal, single
channel control, when done making adjustments.
Page | 410

22.7.9 PAN CONTROL

; See the previous section) the Audio 1A track's display
PAN
M -C P
ULTI HANNEL AN CONTROL
SEL
G A B (M
AIN AND
mode, an additional control (labeled GAIN A or B) appears at
CHAN
button again to restore
SEL
button light will go out.
T )
IC RIM
FIGURE 379
FIGURE 380
