Normally, TriCaster uses its current session settings for video output.
SpeedEDIT projects (created using SpeedEDIT's File menu (New), for example) may
be a various resolutions, however. SpeedEDIT sends output to TriCaster's audio and
video outputs continuously, without selecting any menu setting.
Unlike the arrangement for Live Desktop output, for SpeedEDIT purposes TriCaster's
video outputs (rows 1-3) attempt to conform to the SpeedEDIT project format. So if
the project is HD, TriCaster's SDI outputs will all send HD-SDI, and the analog outputs
will all be Component HD.
Likewise when the project is SD, the SDI outputs will all be SD. As there are multiple
connection options for analog SD video, please refer to the following table in this case:
Row
Number
1
2
Note: When opening projects, TriCaster will attempt to provide hardware video output for
SpeedEDIT, which may require it to reset the display hardware from HD to SD (or vice
versa). It's possible that this could result in a monitor, its connection type, or both being
inappropriate for TriCaster's output mode.
The realtime IEE1394 (DV/HDV) preview found in SpeedEDIT standalone is not
supported for TriCaster, which has other (superior) video display options.
TriCaster launches SpeedEDIT on a desktop of its own, spanning all connected
monitors. You can exit SpeedEDIT by clicking the [x] button in the upper-right corner
of the desktop, or by using the File men item Close.
If you have a secondary monitor connected to TriCaster, you can drag SpeedEDIT's
Video Output window (opened from the Window menu) onto that screen.
Page | 346
21.2.1 SESSIONS, PROJECTS AND DISPLAY
SDI
Analog BNC 1
SD
SD
Composite
21.2.2 IEEE1394 I/O OUTPUT
21.2.3 SPEEDEDIT DESKTOP
Analog BNC
2
Y
Pb
Y
New
Analog BNC
3
Pr
C
