Transport controls and playback settings are located directly below the Playlist and
Scrub-Bar.
FIGURE 193
During playback, a timecode field beside the transport controls
displays the Current Time for the player. This may be the current
time position in the active playlist item (when Single mode is
enabled), or relate to the duration of the entire playlist.
Left-click the field to type in a timecode, then press Enter to jump to that point in the
file (or playlist).
If you right-click the timecode field instead, a menu allows you to choose to between
showing current time and remaining time (Reverse Direction), enabling or disabling
Warning Colors, or toggling Playlist Duration on and off (versus single playlist item
duration).
Hint: With Warning Colors enabled, the time display provides visual indication that the
playback is nearing its end. Ten seconds before the end of play for the current item, the
digits in the time display turn amber. With only five seconds left, numbers are red.
Media Player playback normally conforms to typical playlist practice – each item in
the playlist playing back in orderly succession.
FIGURE 195
Page | 206
11.2.3 PLAYER CONTROLS
T
When Single mode is enabled, playback stops when the Out Point of
the current playlist item is reached (unless Loop is also enabled, in
which case playback of the current item repeats until manually
interrupted).
D
IME
ISPLAY
S
INGLE
FIGURE 194
