SECTION 22.10 TRICASTER MINI MODELS

TriCaster Mini is a highly compact and portable unit. Of course, like any complex
electronic device, it is wise to protect it against accidental damage, including dropping
or falling, as well as static discharges.
FIGURE 409
E DIMENSIONS AND MOUNTING
It's important when planning your installation to provide
adequate support for the unit's weight, and pay particular
attention to providing room for both cable access and adequate
ventilation. This section provides physical dimensions and
recommendations intended to inform and guide you when
mounting TriCaster systems and related control surfaces.
The unit weighs 9 lbs. (4.1 kg).
Passing HDMI cables through
the removable
provides extra strain relief and
security, but it's wise to ensure
cabling is routed in the room to
avoid creating a trip-hazard
even so – especially in desktop
installations.
Free airflow at TriCaster Mini's
vented side panels is also
important for system cooling.
'handle'
