Ricoh Aficio MP C3001 Service Manual page 1393

Bridge Unit (D386)/ Side Tray (D542)
6150
6150 1 Bridge/Left: Exit Sensor
6150 2 Bridge/Left: Feed Sensor
6150 3 Bridge/Left: Shift Set Detection
6150 4 Bridge/Left: Exit Cover Detection
6150 5 Bridge/Left: Feed Cover Detection
6150 6 Left/Left Exit Sensor
Internal Shift Tray (D388)
6152
6152 1 Shift:Set Sensor
6152 2 Shift: Position Sensor
SM Appendix
Description
Description
3-413
Input and Output Check
Reading
0
Paper detected
Paper detected
Set
Closed
Closed
Paper detected
Reading
0
Set
Tray position:
Tray position: front
1
Paper not
detected
Paper not
detected
Not set
Open
Open
Paper not
detected
1
Not Set
rear
D086/D087
