Page 1 EP3010 GENERAL...
Page 2: Table Of Contents
CONTENTS 1. SPECIFICATIONS ................... G-1 2. PRECAUTIONS FOR INSTALLATION ............G-4 3. PRECAUTIONS FOR USE ................G-5 4. HANDLING OF THE CONSUMABLES ............G-6 5. SYSTEM OPTIONS ..................G-7 1. CROSS-SECTIONAL VIEW ................1 2. COPY PROCESS .................... 2 3. DRIVE SYSTEM ....................4 4.
Page 3 15-1.Toner Hopper Locking/Unlocking ............44 15-2.Toner Replenishing ................. 44 15-3.Shutter ..................... 45 15-4.Toner Hopper Home Position Detection ..........45 15-5.Toner Bottle Vibration ................46 15-6.Toner Replenishing Control ..............46 16. PAPER TAKE-UP/FEED SECTION ..............47 16-1.Drawer-in-Position Detection ..............48 16-2.Drawer Paper Lifting/Lowering Mechanism/Control ........ 49 16-3.Paper Level Detection ................
Page 4 28. COOLING FAN ....................84 29. OPTICAL SECTION COOLING FAN ............... 85 30. MEMORY BACKUP ..................86 31. PRECAUTIONS FOR HANDLING THE PWBs ..........1 31-1.Precautions for Transportation and Storage ..........1 31-2.Precautions for Replacement and Inspection .......... 1 32. CONTROL PANEL KEYS AND TOUCH PANEL ..........2 32-1.Control Panel Keys ..................
Page 5 38-2.HANDLING OF THE PC DRUM .............. 1 38-3.PARTS WHICH MUST NOT BE TOUCHED ........... 4 Screws ..................... 4 Variable Resistors on Board ............4 Other Screws ................... 4 39. DISASSEMBLY/REASSEMBLY ..............5 39-1.DOORS, COVERS, AND EXTERIOR PARTS: IDENTIFICATION AND REMOVAL PROCEDURES 5 39-2.REMOVAL OF PWBs ................
Page 6 Removal of the Brush Roller ............41 Cleaning of the Brush Roller ............41 (10) Removal of the Lower Fusing Roller ..........42 (11) Cleaning of the Lower Fusing Roller ..........42 (12) Cleaning of the Lower Paper Separator Fingers ......42 (13) Disassembly of the Exit/Duplex Switching Unit .......
Page 7 Fusing/Exit Misfeed ................. 25 PF-206 Paper Take-Up Misfeed ............27 PF-112 Paper Take-Up Misfeed ............29 AD-11 Vertical Transport/Storage Misfeed ........31 AD-11 Paper Take-Up Misfeed ............34 4. MALFUNCTIONS .................... 36 4-1. Detection Timings Classified by Malfunction Codes ........ 36 4-2.
Page 8 (14) C099E: Shift Gate Position Detecting Failure C099F: Shift Gate Position Detecting Failure C0996: 3rd Drawer Lock Release Failure C0F79: Paper Empty Sensor Failure 71 (15) C0d00: Duplex Unit Front/Rear Edge Guide Plates Home Position Detection Failure C0d20: Duplex Unit Gate Unit Home Position Detection Failure C0d50: Duplex Unit Drive Motor M31’s Failure to Turn C0d51: Duplex Unit Drive Motor M31 Turning at Abnormal Timing 73 (16) C0F02: Original Size Detecting Board UN2 Failure...
Page 9: Specifications
1173SBG0100A SPECIFICATIONS NAME : EP3000 Most Areas Except Europe EP3010 European Areas TYPE : Desktop (with Stationary Platen) PHOTOCONDUCTOR : Organic Photoconductor COPYING SYSTEM : Electrostatic Indirect Image Transfer to Plain Paper PAPER FEEDING : 3-Way Feeding 1st Drawer: Fixed Paper Size Tray (500...
Page 10 MULTIPLE COPIES : 1 to 999 WARMING-UP TIME : 60 sec. or less with room temperature of 23°C and rated power voltage × FIRST COPY TIME : A4C or 8-1/2” 11”C: 6.0 sec. or less (in Full size Mode using 1st Drawer) CONTINUOUS COPY SPEED (copies/min.): Fed from 1st Drawer Zoom Ratio Zoom Ratio...
Page 11 POWER/CURRENT CONSUMPTION (Copier Only) Fusing Exposure Heater Max. Power Voltage Lamp In Standby Lamp Consumption (Rating) (Rating) 115V 115V 1280W 940W 262W 900W 115V 120V 1340W 1000W 262W 900W 115–120V 127V 1410W 1070W 262W 900W 160V 220V 220–240V 1300–1430W 940–1070W 290W 900W POWER...
Page 12: Precautions For Installation
1173SBG0200A PRECAUTIONS FOR INSTALLATION Installation Site To ensure safety and utmost performance of the copier, the copier should NOT be used in a place: • Where it will be subjected to extremely high or low temperature or humidity. • Which is exposed to direct sunlight. •...
Page 13: Precautions For Use
1173SBG0300A PRECAUTIONS FOR USE To ensure that the copier is used in an optimum condition, observe the following precau- tions. • Never place a heavy object on the copier or subject the copier to shocks. • Insert the power plug all the way into the outlet. •...
Page 14: Handling Of The Consumables
1173SBG0400A HANDLING OF THE CONSUMABLES Before using any consumables, always read the label on the container carefully. • Use the right toner. The applicable copier model name is indicated on the Toner Bottle. • Paper can to be easily damaged by dampness. To prevent absorption of moisture, store paper, which has been removed from its wrapper but not loaded into the drawer, in a sealed plastic bag in a cool, dark place.
Page 15: System Options
1173SBG0500A SYSTEM OPTIONS 9,10 1, 2 1151O007AA 1138O525AA 1149M026AA 1174G001AA 7, 8 1139O0020A 1174G002AA 1174G004AA 1174G003AA 1174G006AA 1. Automatic Document Feeder AF-5 7. 10-Bin Sorter S-106 2. Duplexing Document Feeder AFR-12 8. 10-Bin Staple Sorter ST-104 3. Paper Feed Cabinet PF-112 9.
Page 16 EP3010 MECHANICAL/ ELECTRICAL...
Page 17 CONTENTS 1. CROSS-SECTIONAL VIEW ................M-1 2. COPY PROCESS .................... M-2 3. DRIVE SYSTEM ....................M-4 4. SEQUENTIAL EXPLANATION ................ M-5 5. WATCHDOG (CPU OVERRUN MONITOR) FUNCTION ........ M-9 5-1. Configuration ................... M-9 5-2. Watchdog Function Post-Processing ............M-10 6. MALFUNCTION BYPASS FUNCTION ............M-11 6-1.
Page 18 15-6. Toner Replenishing Control ..............M-46 16. PAPER TAKE-UP/FEED SECTION ..............M-47 16-1. Drawer-in-Position Detection ..............M-48 16-2. Drawer Paper Lifting/Lowering Mechanism/Control ....... M-49 16-3. Paper Level Detection ................M-51 16-4. Paper Empty Detection ................M-52 16-5. Universal Tray (2nd Drawer) Paper Size Detection ........ M-53 16-6.
Page 19: Cross-Sectional View
1173SBM0100A CROSS-SECTIONAL VIEW 1151M010AB 1. 3rd Mirror 15. 1st/2nd Drawer Paper Take-Up 2. 2nd Mirror Roll 3. 1st Mirror 16. 1st/2nd Drawer 4. Exposure Lamp 17. Image Transfer/Paper Separator 5. Lamp Reflector Coronas 6. Lens 18. Suction Unit 7. Cleaning Blade 19.
Page 20: Copy Process
1173SBM0200A COPY PROCESS MULTI BYPASS TABLE 1. PC DRUM 8. PAPER SEPARATION 2. DRUM CHARGING 9. CLEANING 1139M002AA 3. IMAGE ERASE 10. MAIN ERASE 4. EXPOSURE 11. TRANSPORT 5. DEVELOPING 12. FUSING 6. PAPER FEEDING 13. PAPER EXIT 7. IMAGE TRANSFER 1.
Page 21 6. Paper Feeding Paper is fed either automatically from the 1st or 2nd Drawer, or manually via the Multi Bypass Table or Manual Bypass Table. Paper separation is accomplished by the torque limiter fitted to the Paper Separator Roll. (For more details, see “16. PAPER TAKE-UP/FEED SECTION”.) 7.
Page 22: Drive System
1173SBM0300A DRIVE SYSTEM This copier is equipped with two main drive motors, the PC Drive Motor that drives the upper half of the copier (Imaging Unit) and the Main Drive Motor which drives the lower half of the copier (paper take-up/feeding, transport mechanism and Fusing Unit). Each has its own drive transmitting gears and timing belts as illustrated below.
Page 23: Sequential Explanation
1173SBM0400A SEQUENTIAL EXPLANATION Numbers given in rectangles in the following flowchart are timer values in seconds. A The power cord is plugged into the outlet. Power cord is plugged in. DC24V for Drum heating (Power Supply Unit) Drum Dehumidifying Only when Dehumidifying Heater Switch is ON Paper Dehumidifying...
Page 24 D The Start Key is pressed. Start Key ON Main Drive Motor Synchronizing Roller Clutch For approx. 0.2 sec. only Paper Transport Clutch 1st/2nd Drawer Paper Take-Up Motor 1st Drawer: Approx. 0.5 PC Drive Motor 2nd Drawer: Approx. 1.1 Main Erase Lamp Image Erase Lamp All LEDs are turned ON.
Page 25 Approx. Scanner Motor Scanner Reference Position Sensor Main Erase Lamp OFF Approx. Image Erase Lamp LEDs ON/OFF 0.03 control is started. TRON Signal Synchronizing Roller Clutch Paper Transport Clutch Approx. Separator Solenoid Approx. Separator Solenoid F A scan motion is completed. SCEND signal: LOW Approx.
Page 26 G The last paper moves past Transport Roller Sensor. Transport Roller Sensor OFF Paper Leading Edge Detecting Sensor Approx. Approx. Synchronizing Roller Clutch Approx. PC Drum Charge Corona/Image Transfer Corona (High Voltage Unit) Approx. PC Drive Motor Main Erase Lamp Image Erase Lamp Approx.
Page 27: Watchdog (Cpu Overrun Monitor) Function
1173SBM0500A WATCHDOG (CPU OVERRUN MONITOR) FUNCTION The watchdog function monitors whether any of the CPUs mounted in the copier overrun. If this function detects that a CPU overruns, the copier automatically resets the CPU, thereby restarting the logic circuit and mechanism. Even if a copier CPU operates erratically due to electrical noise, therefore, the copier is able to recover from the faulty condition so that the number of visits made by the Technical Representative for CPU overrun can be minimized.
Page 28: Watchdog Function Post-Processing
1173SBM0502A 5-2. Watchdog Function Post-Processing The following processing is performed if a faulty condition is detected in the CPU. When the copier CPU is found faulty: • All CPUs including those of the options are reset and the system is restarted. If the CPU is found faulty during a copy cycle, the system attempts to feed all sheets of paper out of the copier before resetting.
Page 29: Malfunction Bypass Function
1173SBM0600A MALFUNCTION BYPASS FUNCTION • When a malfunction occurs in the copier, the malfunction bypass function permits the copier to continue operating if that malfunction is one of the predefined candidates for an isolated malfunction and if it will not affect the current copying operation. But, if an iso- lated malfunction occurs anytime during the actual copy cycle, the copier considers it a normal malfunction.
Page 30: Image Stabilization System
1173SBM0700A IMAGE STABILIZATION SYSTEM The following image stabilization controls are provided to ensure stabilized copy image. Item Quality Purpose Control Initial Setting Image density, To make initial settings of Sets the initial values for gradation grid voltage (Vg), optimum grid voltage correction, opti- Exposure Lamp voltage, mum Exposure Lamp volt- and AE Sensor gain.
Page 31: Aldc Sensor
1173SBM0701A 7-1. AlDC Sensor To provide image stabilization control, this copier has the AlDC Sensor fitted to the Clean- ing Unit of the Imaging Unit. The sensor is used to detect the toner density and background level on the PC Drum. Operation 1.
Page 32: Image Stabilization Control Processing Timing
1173SBM0702A 7-2. Image Stabilization Control Processing Timing • The image stabilization controls use the AIDC Sensor and AE Sensor as the basis for performing the following four major types of processing. • The grid voltage, T/C, and optimum Exposure Lamp corrections are not, however, made if T/C falls outside the range of 4% to 8% at adjustment.
Page 33: Details Of Image Stabilization Controls
1173SBM0703A 7-3. Details of Image Stabilization Controls 1. AIDC Sensor adjustment 3. Optimum Exposure Lamp voltage 2. Grid voltage and T/C correction correction 4. AE Sensor gain adjustment • The following are the details of each image stabilization control. 1-1. AIDC Sensor coarse adjustment This adjustment represents a coarse adjustment of the AIDC Sensor when the ordinary control of only the LED current cannot cover part-to-part variations in the AIDC Sensor (installation, circuit, deterioration, etc.).
Page 34 <Relation with Image Density> The “Image Exposure” function of “Tech. Rep. Choice” available from the Tech. Rep. mode enables fine-adjustments of the grid voltage (solid-black image density) to be made. It specifies how many volts the optimum grid voltage determined by the image stabilization control is to be increased or decreased.
Page 35: Imaging Unit
1173SBM0800A IMAGING UNIT This copier is equipped with an Imaging Unit, or IU, which integrates a PC Drum, PC Drum Charge Corona, Developing Unit, Cleaning Unit, and Toner Recycling mechanism into one assembly. The Unit also includes the Upper Synchronizing Roller which facilitates clearing of a paper misfeed.
Page 36: Imaging Unit Drive
1173SBM0801A 8-1. Imaging Unit Drive Drive for the Imaging Unit is transmitted by one of the gears on the Unit. This particular gear is in mesh with the Imaging Unit Drive Gear in the copier. Developer Mixing Screw Drive Gear Bucket Roller Drive Gear Imaging Unit Drive Sleeve/Magnet Roller...
Page 37: Pc Drum
1173SBM0900A PC DRUM The photoconductive drum used in this copier is the organic photoconductor (OPC) type. The drum is made up of two distinct, semiconductive materials on an aluminum alloy base. The outer of the two layers is called the Charge Transport Layer (CTL), while the inner layer is called the Charge Generating Layer (CGL).
Page 38: Drum Charging
1173SBM1000A DRUM CHARGING The PC Drum Charge Corona has a Scorotron grid to deposit a negative DC charge evenly across the surface of the PC Drum. The grid voltage (VG) applied to the grid mesh is selected between –550V (initial value, variable according to image stabilization controls) in the normal mode and the value in the normal mode +90V in the Photo mode by the Con- stant-Voltage Circuit in the High Voltage Unit.
Page 39: Image Erase Lamp
1173SBM1100A IMAGE ERASE LAMP To prevent a black band from occurring across both the leading and trailing edges, and along the front and rear edges, of the electrostatic latent image, 38 LEDs of the Image Erase Lamp are turned ON before development takes place, thereby reducing to a mini- mum the unnecessary potential on the surface of the PC Drum.
Page 40 The 38 LEDs are grouped as follows and turned ON and OFF according to the paper size and zoom ratio. LED Group No. LED No. LED Group No. LED No. LED 1 LED 23 LED 2 LED 24 LED 3 to 5 LED 25 LED 6 to 8 LED 26...
Page 41 • Image Erase Lamp LEDs ON/OFF Pattern (Control is provided to turn ON more LEDs when the ON/OFF pattern varies between a zoom ratio and paper width.) Paper LED Group No. Zoom Ratio Width 01 02 03 04 05 06 07 08 09 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 (mm) –...
Page 42 1173T15MCA Control Signal WIRING DIAGRAM Dynamic ON/ PWB-A PJ13A-1~14 OFF Control M-24...
Page 43: Optical Section
1173SBM1200A OPTICAL SECTION As the Scanner is moved by the Scanner Motor, the light from the Exposure Lamp is reflected off the original and guided through the four Mirrors onto the surface of the PC Drum to form the electrostatic latent image. The image is enlarged or reduced as necessary by changing the position of the Lens and 4th Mirror and varying the angle of the 4th Mirror.
Page 44: 12-1.Exposure Lamp
1173SBM1201A 12-1. Exposure Lamp An AC halogen lamp is used as an Exposure Lamp. As the exposure level is adjusted on the control panel, the duty ratio of the pulse of AVR Remote from the Master Board changes to increase or decrease the Exposure Lamp volt- age, thereby changing the image density.
Page 45: Exposure Lamp
1173SBM1202A 12-2. AE Sensor In the Auto Exposure Mode, the AE Sensor on AE Sensor Board measures the intensity of the light reflected off the original, by sampling the black/white ratio of a 210-mm-wide area of the original being measured. According to this measurement, the Exposure Lamp volt- age is automatically increased or decreased so that copies of consistent quality are pro- duced.
Page 46: 12-3.Lamp Reflectors
1173SBM1203A 12-3. Lamp Reflectors The Main Reflector ensures that light from the Exposure Lamp exposes all areas of the original. The Auxiliary Reflector reflects light onto the areas that the Exposure Lamp cannot illuminate when an original that does not lie flat on the Original Glass (such as a book) is being used.
Page 47: 12-5.Scanner And 2Nd/3Rd Mirror Carriage Movement
1173SBM1205A 12-5. Scanner and 2nd/3rd Mirror Carriage Movement The Scanner and 2nd/3rd Mirrors Carriage are moved by the Scanner Drive Cable fitted in the rear side of the copier. The Cable is driven by the Scanner Motor. Both the Scanner and 2nd/3rd Mirrors Carriage slide along the Scanner Shaft at the rear side.
Page 48 The Scanner starts the scan motion when a Scan signal is output from the Master Board. At the start of a scan motion and other heavy load conditions, the Scanner Motor requires a large amount of current. The Current 1 or 2 signal from the Motor Drive Board is selected accordingly to vary the amount of current supplied to the Scanner Motor.
Page 49: 12-6.4Th Mirror Movement
1173SBM1206A 12-6. 4th Mirror Movement The 4th Mirror is moved to vary the conjugate distance for a particular zoom ratio by driving the rack-and-pinion gears at the front and rear ends of the mirror using the Mirror Motor (stepping motor). The Levers of the Holder to which the Mirror is mounted slide along a tilted rail to change the Mirror angle.
Page 50: 12-7.Lens Movement
1173SBM1207A 12-7. Lens Movement The Lens is moved by the Lens Drive Cable which is driven by the Lens Motor (stepping motor). The motor drive pulses sent from the Motor Drive Board drive the Lens Motor to move the Lens a given distance, corresponding to the zoom ratio, from the reference posi- tion determined by Lens Reference Position Sensor.
Page 51: Original Size Detecting Sensors
1173SBM1300A ORIGINAL SIZE DETECTING SENSORS The five sensors fixed in the optical section receive the light reflected off the original to determine the size of the original in the Auto Paper and Auto Size mode. (The image den- sity of the original, or OD, that can be detected is 0.6 or less.) 1173SBM1301A 13-1.
Page 52: 13-3.Sensor Locations
1173SBM1303A 13-3. Sensor Locations • The number and location of the Original Size Detecting Sensors vary depending on the marketing area as shown below. Sensors Areas (PC114) (PC116) (PC117) (PC113) (PC115) Metric Areas Inch Areas Mixed inch/metric Areas : Standard : Optional NOTE: If the optional sensors are installed, set Jumper Connector JP2 on the Original Size Detect-...
Page 53: 13-4.Size Detection
1173SBM1304A 13-4. Size Detection • Original Size Detecting Board reads the output data provided by the original size detect- ing sensors. By comparing the data from each sensor with the threshold level, it deter- mines whether there is an original placed on the Original Glass. Original Size Detecting Board then determines the size of the original according to the combination of the data.
Page 54: Original Size Detection Timing
1173SBM1305A 13-5. Original Size Detection Timing Master CPU on Master Board affirms and resets the readings of the original size at the fol- lowing timings. • Takes size readings: When the Original Cover is raised to an angle of 15° or more (Origi- nal Cover Detecting Sensor is deactivated) •...
Page 55: Original Cover Angle Detection
1173SBM1306A 13-6. Original Cover Angle Detection The Original Cover Detecting Sensor detects the angle of the Original Cover as it is raised. The following control is provided. Original Cover raised to an angle of 15° or more: The size of the original is read by the Original Size Detecting Sensors. Original Cover raised to an angle of less than 15°: When the Original Cover Detecting Sensor is activated, the master CPU of Master Board latches the original size data transmitted by Original Size Detecting Board.
Page 56: Development
1173SBM1400A DEVELOPMENT The Developing Unit built into the Imaging Unit performs the following functions: • Mixes the toner and carrier well to ensure that a sufficient amount of toner is positively charged. • Detects the toner-to-carrier ratio of the developer by means of the ATDC Sensor and replenishes the supply of toner as necessary.
Page 57: 14-1.Atdc Sensor
1173SBM1401A 14-1. ATDC Sensor The copier compares the toner-to-carrier ratio (T/C) of the developer in the Developer Mix- ing Chamber detected by ATDC Sensor during a copy cycle with the reference ratio (6%) and, if it finds a lower ratio than the reference, replenishes the supply of toner. The standard output voltage of the ATDC Sensor for the reference T/C (6%) is 2.5V.
Page 58 Toner Empty Detection The copier has no toner empty detecting sensor and, instead, the ATDC Sensor performs that function. The ATDC Sensor checks the toner-to-carrier ratio and, if it reads a T/C ratio lower than the reference level for 37 copies and, further, if it next reads a ratio 1% lower than the reference level, this is a toner-empty condition.
Page 59: 14-2.Magnet Roller
1173SBM1402A 14-2. Magnet Roller The Magnet Roller of the Sleeve/Magnet Roller of this copier has the following magnetic characteristics. Part of pole S2 before the principal N1 pole (i.e., the area marked as S2b in the Fig. below) provides a very weak magnetic force. If developer is compacted and clogs at the Doctor Blade and, as a result, part of the surface of the Sleeve/Magnet Roller is not covered with developer, the nearby developer around S2b goes to those uncovered areas because of the weak magnetic force.
Page 60: 14-3.Developing Bias
1173SBM1403A 14-3. Developing Bias A negative voltage (Vb = Developing Bias voltage) is applied to the Sleeve Roller to prevent a foggy background on the copy. The amount of toner attracted onto the surface of the PC Drum depends on how much lower the PC Drum surface potential (Vi) is than Vb (i.e., the potential difference).
Page 61: 14-4.Doctor Blade
1173SBM1404A 14-4. Doctor Blade The Doctor Blade installed over the Sleeve/Magnet Roller regulates the height of the devel- oper brush on the surface of the Sleeve Roller. The Blade is perpendicular to the direction of movement of the Magnet Roller to minimize variations in the distance between the Doc- tor Blade and Magnet Roller as the Magnet Roller moves.
Page 62: Toner Hopper
1173SBM1500A TONER HOPPER 1173SBM1501A 15-1. Toner Hopper Locking/Unlocking The Toner Hopper is not integrated into the Imaging Unit; instead, it is secured to the copier. To replace an empty Toner Bottle, the user first needs to swing the Toner Bottle Holder out 40°...
Page 63: 15-2.Toner Replenishing
1173SBM1503A 15-3. Shutter The connection between the Toner Hopper and Imaging Unit is provided with a Shutter which prevents toner from spilling when the Imaging Unit is slid out of the copier. Imaging Unit Out of Copier Imaging Unit in Position in Copier Shutter 1139M026AA 1139M027AA...
Page 64: 15-5.Toner Bottle Vibration
1173SBM1505A 15-5. Toner Bottle Vibration When the indentations at three places near the left end (as viewed when the Toner Bottle is in position) of the Toner Bottle move past the protrusion in the Toner Bottle Holder, the Toner Bottle is vibrated to prevent some of the toner from remaining unconsumed in the Bottle.
Page 65: Paper Take-Up/Feed Section
1173SBM1600A PAPER TAKE-UP/FEED SECTION The copier is equipped with two paper drawers that can be slid out to the front of the copier. The 1st Drawer is a fixed paper size type, while the 2nd Drawer is a universal paper size type.
Page 66: 16-1.Drawer-In-Position Detection
1173SBM1601A 16-1. Drawer-in-Position Detection • When the drawer is slid into the copier, Drawer Set Detecting Lever A is pushed in the direction of the arrow, which blocks the Drawer Set Sensor (goes LOW). Rear 1st/2nd Drawer Set Sensor PC61,62 Front 4425M003AA Control Signal...
Page 67: 16-2.Drawer Paper Lifting/Lowering Mechanism/Control
1173SBM1602A 16-2. Drawer Paper Lifting/Lowering Mechanism/Control • The paper lifting mechanism raises the paper in the drawer so that the top of the paper stack is pressed against the Paper Take-Up Roll at a constant pressure. • When slid into the copier, the drawer presses the Drawer Set Lever which engages Lift- Up Motor Gear 1 with Paper Lifting Arm Gear 2.
Page 68 During Copying • As sheets of paper are used, the Paper Take-Up Roll lowers accordingly, unblocking the Lift-Up Sensor (goes HIGH). 4425M006AA • The Lift-Up Motor starts running, raising the paper stack until the Lift-Up Sensor is blocked (output goes LOW). 4425M005AA •...
Page 69: 16-3.Paper Level Detection
1173SBM1603A 16-3. Paper Level Detection • The amount of paper still available for use, or the paper level, of the 1st and 2nd Drawer is detected by 1st/2nd Drawer Lift-Up Motor Pulse Sensor and a pulse disk. • The pulse disk is mounted on the shaft of the intermediary gear that transmits drive from the Lift-Up Motor.
Page 70: 16-4.Paper Empty Detection
1173SBM1604A 16-4. Paper Empty Detection • A paper empty condition in the 1st and 2nd Drawers is detected by 1st Drawer Paper Empty Sensor and 2nd Drawer Paper Empty Sensor, respectively, installed in the paper take-up area of each drawer. •...
Page 71: 16-5.Universal Tray (2Nd Drawer) Paper Size Detection
1173SBM1605A 16-5. Universal Tray (2nd Drawer) Paper Size Detection • The length (feeding direction) and width (crosswise direction) of the paper are indepen- dently detected and the copier determines the paper size by combining the two separate detections made. The “Universal Tray 13”x or 14x” function of “Tech. Rep. Choice” must be set for the length (FD) of FLS (13”...
Page 72 • Paper Size Detecting Switches/Sensors Length FD Width CD PC72 PC73 1149M017AA 1149M018AA • Details of Paper Size Detecting Switches/Sensors Operation and Detectable Paper Sizes Paper Size Detecting Switches/Sensors CD × FD Paper Size Inch Size Length (FD) Width (CD) (mm) S64 PC72 PC73 148 ×...
Page 73 Control Signal Deactuated Actuated WIRING DIAGRAM PWB-A PJ21A-2 12-A PWB-A PJ21A-4 12-A PWB-A PJ21A-7 13-A PWB-A PJ21A-9 13-A Control Signal Unblocked Blocked WIRING DIAGRAM PC72 PWB-A PJ32A-2 PC73 PWB-A PJ32A-5 M-55...
Page 74: 16-6.Paper Take-Up Mechanism
1173SBM1606A 16-6. Paper Take-Up Mechanism 1173SBM160601A (1) Paper Take-Up Mechanism • The paper take-up and feeding mechanism takes up paper from the drawer and feeds it to the Vertical Transport Roller. • The take-up mechanism is driven by 1st/2nd Drawer Paper Take-Up Motor. •...
Page 75: Paper Separating Mechanism
1173SBM160602A (2) Paper Separating Mechanism • The paper separating mechanism ensures that only the top sheet of paper is fed in by separating the second sheet of paper from the top one. • This is accomplished by the difference in friction coefficient between the first and second sheets of paper.
Page 76: Paper Pressure Releasing Mechanism
1173SBM160603A (3) Paper Pressure Releasing Mechanism • If the drawer is pulled out while the paper is between the Feed Roll and the Separator Roll, the paper is left in the copier. Removal of the paper is difficult. With this copier, slid- ing out the drawer automatically disengages the paper and Paper Take-Up/Feed Roll.
Page 77: 16-7.Drawer Paper Take-Up Control
1173SBM1607A 16-7. Drawer Paper Take-Up Control 1173SBM160701A (1) Paper Take-Up Motor Control • A stepping motor is used for the Paper Take-Up Motor. Each motor is turned forward or backward by energizing its four internal coils using the pulse signals output from Master Board.
Page 78: Paper Take-Up Retry Control
1173SBM160702A (2) Paper Take-Up Retry Control • To minimize the occurrence of paper misfeed due to a slippery Paper Take-Up Roll, the Paper Take-Up Motor is kept deenergized for a given period of time before it is energized again, if a sheet of paper fails to reach the Paper Take-Up Sensor even after the lapse of a given period of time after the motor has first been energized.
Page 79: 16-8.Vertical Paper Transport
1173SBM1608A 16-8. Vertical Paper Transport The sheet of paper taken up by the Paper Take-Up Roll from the Drawer is fed along the Paper Guide to the Vertical Transport Rollers. The paper fed by the Vertical Transport Roll- ers reaches the Transport Rollers and is then fed up to the Synchronizing Rollers. The Transport Rollers are turned and stopped by the Paper Transport Clutch.
Page 80: Multi Bypass Table
1173SBM1700A MULTI BYPASS TABLE The Multi Bypass Table permits the user to make multiple copies (up to 50) on paper that cannot be fed automatically via any built-in paper drawer of the copier. Lever Manual Feed Paper Empty Sensor PC31 Manual Feed Paper Take-Up Clutch CL51...
Page 81: 17-1.Paper Take-Up Mechanism
1173SBM1701A 17-1. Paper Take-Up Mechanism The Paper Take-Up Rolls are normally in their raised (retracted) position so that they will not hamper proper loading of paper. When the Start Key is pressed, Manual Feed Paper Take-Up Solenoid is deenergized causing the Paper Take-Up Rolls to press the paper stack downward and take up a sheet of paper.
Page 82: 17-2.Paper Take-Up Retry Control
1173T17MCA Control Signal Energized Deenergized WIRING DIAGRAM CL51 PWB-A PJ14A-4 17-H SL51 PWB-A PJ14A-2 Down 17-H SL51 PWB-A PJ14A-3 1173SBM1702A 17-2. Paper Take-Up Retry Control To minimize the occurrence of a paper misfeed due to a slippery paper Take-Up Roll, the Manual Feed Paper Take-Up Clutch is kept deenergized for a given period of time before it is energized again, if a sheet of paper fails to reach the Transport Roller Sensor even after the lapse of a given period of time after the clutch has first been energized.
Page 83: 17-3.Paper Separating Mechanism
1173SBM1703A 17-3. Paper Separating Mechanism The paper separating mechanism ensures that only the top sheet of paper is fed in by sep- arating the second sheet of paper from the top one. This is accomplished by the Torque Limiter fitted to the Separator Roll shaft which stops the Separator Roll when there is a change in friction between the Feed and Separator Rolls.
Page 84: Synchronizing Rollers
1173SBM1800A SYNCHRONIZING ROLLERS The Synchronizing Rollers, operating in phase with the Scanner scan motion and paper feeding, synchronize the leading edge of the copy paper accurately with the leading edge of the toner image on the PC Drum. The Upper Synchronizing Roller is a metal roller covered with a polyvinyl chloride tubing, while the Lower one is a rubber roller.
Page 85: 18-1.Upper Synchronizing Roller Positioning
1173SBM1801A 18-1. Upper Synchronizing Roller Positioning Since the Upper Synchronizing Roller is fitted to the Imaging Unit, it must be correctly posi- tioned with reference to the Lower Synchronizing Roller when the Upper Half of the copier is swung down into the locked position. For this purpose, slots are cut in the lower copier frame and the Bushings of the Upper Synchronizing Roller fit into these slots.
Page 86: 18-3.Synchronizing Roller Control
1173SBM1803A 18-3. Synchronizing Roller Control The Synchronizing Rollers are started as the Synchronizing Roller Clutch is energized upon reception of a signal from the Master Board. 1173T10MCA Control Signal Energized Deenergized WIRING DIAGRAM PWB-A PJ11A-4B Control Signal Blocked Unblocked WIRING DIAGRAM PC54 PWB-A PJ15A-2 M-68...
Page 87: Image Transfer And Paper Separation
1173SBM1900A IMAGE TRANSFER AND PAPER SEPARATION Image Transfer The Image Transfer Corona applies a DC negative corona emission to the underside of the paper thereby attracting the positively charged toner onto the surface of the paper to form a visible, developed image of the original. The Corona Unit is provided with a Corona Wire cleaning mechanism: the operator has only to pull out the Lever on which the Cleaner is mounted from the front of the copier, which cleans the Wire.
Page 88 1151T07MCB Control Signal WIRING DIAGRAM Image Transfer PWB-A PJ27A-2 Corona Paper Separator PWB-A PJ27A-3 Corona M-70...
Page 89: Main Erase Lamp
1173SBM2000A MAIN ERASE LAMP Main Erase Lamp is turned ON to neutralize any surface potential remaining on the surface of the PC Drum after cleaning. PC Drum Main Erase Lamp LA2 Charge Corona PC Drum 1149M012AA The Main Erase Lamp is not a single lamp. A total of 40 LEDs are mounted on a board to make up Main Erase Lamp.
Page 90: Paper Separator Fingers
1173SBM2100A PAPER SEPARATOR FINGERS After image transfer, an AC corona emission is applied to the underside of the paper by the Paper Separator Corona to neutralize the paper so that it can be easily separated from the PC Drum. To further ensure that the paper is positively separated from the PC Drum, there are two Paper Separator Fingers attached to the Imaging Unit.
Page 91 1151T13MCC Control Signal Energized Deenergized WIRING DIAGRAM PWB-A PJ7A-4 M-73...
Page 92: Cleaning Unit
1173SBM2200A CLEANING UNIT 1173SBM2201A 22-1. Cleaning Unit The Cleaning Blade is pressed tightly against the surface of the PC Drum and scrapes off any toner remaining on the surface after image transfer and paper separation have been completed. The Cleaning Blade is moved back and forth to prevent the PC Drum from deteriorating and the Cleaning Blade from warping away from the surface of the PC Drum.
Page 93: 22-2.Cleaning Bias
1173SBM2202A 22-2. Cleaning Bias Except the U.S.A., Canada, and Europe There is a Cleaning Bias Seal installed to minimize damage to the PC Drum from acid paper. Toner Antispill Mylar PC Drum 1139M023AA Cleaning Bias Seal 1151T02MCB Control Signal WIRING DIAGRAM Cleaning Bias M-75...
Page 94: Paper Transport
1173SBM2300A PAPER TRANSPORT After having gone through the image transfer and paper separation processes, the paper is then transported to the Fusing Unit by the Suction Belts of the Suction Deck driven directly by the Main Drive Motor. The Suction Fan Motor draws the paper onto the turning Suction Belts for positive transport of the paper.
Page 95: Fusing Unit
1173SBM2400A FUSING UNIT The Upper Fusing Roller and Lower Fusing Roller together apply heat and pressure to the toner and paper to permanently fix the developed image to the paper. Drive for the Upper Fusing Roller is transmitted from the Main Drive Motor to the Upper Fusing Roller Drive Gear.
Page 96: 24-1.Fusing Temperature Control
1173SBM2401A 24-1. Fusing Temperature Control The Upper Fusing Roller is heated by a Fusing Heater Lamp which is an AC halogen lamp. Fusing Thermistor 1 and 2 installed on the Upper Fusing Roller help keep the optimum fus- ing temperature. The fusing temperature is normally controlled at 195°C.
Page 97: 24-2.Fusing Rollers Pressure Mechanism
<Fusing Temperature Control During Continuous Small-Size Paper Feeding> When a number of sheets of small-size paper are fed through the copier continuously, the temperature of the rear end of the Fusing Rollers tends to rise, resulting in high-tempera- ture offset occurring. Fusing Thermistor is installed at a location 278.5 mm from the posi- tion of paper passage registration.
Page 98: 24-3.Brush Roller/Cleaning Roller
1173SBM2403A 24-3. Brush Roller/Cleaning Roller • The Brush Roller is pressed up against the Upper Fusing Roller. It turns in the direction opposite that of the Upper Fusing Roller and, with its brush, removes toner and paper dust. • The Cleaning Roller is made up of an aluminum cylinder around which a high tempera- ture resistant paper based material is wound.
Page 99: Exit Unit
1173SBM2500A EXIT UNIT The Paper Exit Roller/Rolls feed the paper, to which the developed image has been fixed, out of the Fusing Unit to the Exit/Duplex Switching Unit. The Charge Neutralizing Brush touches the surface of the sheet of paper being fed out of the Fusing Unit to neutralize any static charge left on it.
Page 100: Exit/Duplex Switching Unit
1173SBM2600A EXIT/DUPLEX SWITCHING UNIT The Exit/Duplex Switching Unit has the following functions: • Transmits the copier drive to the Sorter/Staple Sorter. • Locks the Sorter/Staple Sorter in position. • Selects the paper path, either to the exit or to the Duplex Unit, when the copier is equipped with a Duplex Unit.
Page 101: Dehumidifying Switch (Option)
1173SBM2700A DEHUMIDIFYING SWITCH (OPTION) To prevent image transfer efficiency from being reduced due to damp paper in highly humid weather, Paper Dehumidifying Heater is installed on the base frame of the copier under the 2nd Drawer. A Drum Dehumidifying Heater is located under the Lower Synchronizing Roller to prevent the PC Drum from forming condensation.
Page 102: Cooling Fan
1173SBM2800A COOLING FAN Ozone produced by the PC Drum Charge Corona and Image Transfer/Paper Separator Coronas is drawn out of the copier by the Cooling Fan Motor and absorbed by the Ozone Filter. The Cooling Fan Motor is turned either at high or low speed. It turns at high speed while Main Drive Motor or PC Drive Motor is being energized.
Page 103: Optical Section Cooling Fan
1173SBM2900A OPTICAL SECTION COOLING FAN The Optical Section Cooling Fan Motor draws outside air into the copier and blows it against the Original Glass which is heated by the lit Exposure Lamp. The Filter at the intake port of the Fan prevents dust and dirt from entering the Optical Sec- tion of the copier.
Page 104: Memory Backup
1173SBM3000A MEMORY BACKUP IC1 (RAM) of the RAM Board connected to the Master Board stores the setting/adjustment values set in the Tech. Rep. Modes as well as the counter counts. The Backup Battery is mounted on the RAM Board to prevent the contents of memory from being lost when the power cord is unplugged or the RAM Board removed from the copier.
Page 105 EP3010 SWITCHES ON PWBs/ TECH. REP. SETTINGS 17196...
Page 106 CONTENTS 1. PRECAUTIONS FOR HANDLING THE PWBs ..........S-1 1-1. Precautions for Transportation and Storage ..........S-1 1-2. Precautions for Replacement and Inspection .......... S-1 2. CONTROL PANEL KEYS AND TOUCH PANEL ..........S-2 2-1. Control Panel Keys .................. S-2 2-2.
Page 107: Precautions For Handling The Pwbs
PRECAUTIONS FOR HANDLING THE PWBs 31-1. Precautions for Transportation and Storage A. Before transporting or storing the PWBs, put them in protective conductive cases or bags so that they are not subjected to high temperature (and they are not exposed to direct sunlight).
Page 108: Control Panel Keys And Touch Panel
CONTROL PANEL KEYS AND TOUCH PANEL For more details, see the “Operator’s Manual” shipped with the copier. 32-1. Control Panel Keys 1149O002EA 1. Display Contrast Knob 8. Panel Reset Key • Varies the brightness of the Touch Panel. • Clears all control panel settings made 2.
Page 109: 32-2.Explanation Of The Touch Panel
32-2. Explanation of the Touch Panel (1) Basic Screen • The Basic screen is an initial screen that appears when the copier is turned ON, panel is reset, or when auto clear is activated. 1173S008CA 1. Supplementary Function Keys 3. Basic Function Keys •...
Page 110: Warning Screens
(2) Warning Screens • The warning screen may be a malfunction display, error display, warning display, or a caution display. <Malfunction Display> <Error Display> • A malfunction display is given when • An error display is given when trouble trouble occurs which cannot be cor- occurs which can be corrected by the rected by the user.
Page 111: Functions Of Switches And Points On Pwb
FUNCTIONS OF SWITCHES AND POINTS ON PWB 33-1. PWB Location PWB-A 1149S001AA 33-2. Master Board PWB-A 1149S003CA Symbol Name Description Trouble Reset Switch Resets a malfunction including those of the Exposure Lamp (C04XX) and fusing (C05XX). PJ29 Initialize Switch Forcibly resets a misfeed or malfunction that occurred due to incorrect operation, etc.
Page 112 <Clearing Procedures> • Initialize Points PJ29 1. Turn OFF the Power Switch. 2. With PJ29 closed, turn ON the Power Switch. 3. In approx. 5 sec. open PJ29. 4. Check that the message “Initialize completed” is shown on the Touch Panel, then touch “OK.”...
Page 113: User's Choice Mode
USER’S CHOICE MODE • The User’s Choice mode available from the User Mode menu is used to make various settings according to the user’s needs. 34-1. User’s Choice Selection Screen 1173S001CB 34-2. User’s Choice Function Setting Procedure <Setting Procedure> 1. Press the User Mode key on the control panel and then touch the [User’s Choice] key. 2.
Page 114: 34-3.User's Choice Function Tree
34-3. User’s Choice Function Tree Mixed Original Detect Language Selection Paper Priority Copy Mode Priority Manual Feed Expansion Exposure Mode Priority Exposure Level Priority Manual Exposure Adjust Finishing Priority Auto Panel Reset Energy Saver Mode Drum Dehumidifier User’s Choice Counter Removal Intelligent Sort Confirmation Beep Original Thickness...
Page 115: 34-4.Settings In The User's Choice
34-4. Settings in the User’s Choice [1/6] Touch Panel Highlighted Setting (The default is Display Mixed Original Select whether to enable (“ON”) the Mixed Original Detection mode or Detection not (“OFF”) when power is turned ON or the Panel Reset key pressed. Language Select the language of the Touch Panel messages.
Page 116 [2/6] Touch Panel Setting (The default is Highlighted Display Exposure Mode Specify the default exposure mode selected automatically when Priority power is turned ON or the Panel Reset key pressed. Manual Auto Exposure Level Auto: Select the default exposure level in the Auto Exposure mode. Priority Manual: Set the default exposure level in the Manual Exposure mode.
Page 117 [3/6] Touch Panel Highlighted Setting (The default is Display Auto Panel Reset Specify the default exposure mode selected automatically when power is turned ON or the Panel Reset key pressed. 30 sec. 2 min. 1 min. 3 min. 5 min. No Reset Energy Saver Set the time it takes the copier to enter the Energy Saver mode after a...
Page 118 [4/6] Touch Panel Highlighted Setting (The default is Display Intelligent Sort Select whether to turn “ON” or “OFF” the function that automatically switches between Sort and Non-Sort according to the number of orig- inals loaded in the document feeder. NOTE This function is enabled when “Mixed Orig.
Page 119 [5/6] Touch Panel Highlighted Setting (The default is Display Custom 2in1 Make the settings of “Paper,” “Zoom,” “Margin,” and “Erase” that are automatically recalled when the 2-in-1 copy is selected. Function Description Initial Setting Paper Auto Paper, sizes of paper loaded in Auto Paper drawers Zoom...
Page 120 [6/6] Touch Panel Setting (The default is Highlighted Display Orig. Copy Select the type of Orig. Copy setting selected automatically when Default the copier is turned ON or Panel Reset key pressed. If “Duplex only” is selected for “Simplex/Duplex” of the “Tech. Rep. Choice” function, neither 1 1 nor 1 2in1 are displayed.
Page 121 [6/6] Touch Panel Highlighted Setting (The default is Display 1/25 <100 Accounts> The copy track data of the selected page is displayed (Account No., Total Counter, Size Counter, Limit, ID). “Count Reset”:Clears the total and size counters of all accounts. 22/25 “No.”...
Page 122: Tech. Rep. Mode
TECH. REP. MODE • This mode is used by the Tech. Rep. to set, check, adjust, and/or program various ser- vice functions. 35-1. Tech. Rep. Mode Menu Screen 1173S002CA 35-2. Tech. Rep. Mode Function Setting Procedure <Setting Procedure> 1. With the Meter Count screen opened from User Mode, press the flowing keys in this order.
Page 123: 35-3.Tech. Rep. Mode Function Tree
35-3. Tech. Rep. Mode Function Tree F1 Paper Passage Paper Path Sensors F3 Exp. Lamp F5 Optimum & AE F7 Orig. Sensor Function Developer F8 ATDC Adjust FF F8+F5 Tech. Rep. Choice 1/2 Maintenance Call Toner Empty Stop Auto Paper Config. Leading Edge Erase Trailing Edge Erase Loop Adjust (Drawer)
Page 124 IC Port Data Check Paper Path Sensors Check I/O Check Memory Check Controller Board Check Rom Version Tech. Rep. RD Mode Mode ADF Check Accessory Test Sorter Check Level History Machine Status Admin. Mode S-18...
Page 125: 35-4.Settings In The Tech. Rep. Mode
35-4. Settings in the Tech. Rep. Mode (1) Function • This function allows the Tech. Rep. to make the various functional tests and adjustments. <Setting Procedure> 1. Select the particular function to be run. 2. Press the Start key to start the test. 3.
Page 126: Tech. Rep. Choice
(2) Tech. Rep. Choice • This function allows the Tech. Rep. to make various settings and adjustments. [Tech. Rep. Mode Tech. Rep. Choice] Touch Panel Display Setting (The default is Highlighted Maintenance Call Select whether to enable or disable the maintenance call reminder message that is displayed when the maintenance counter count reaches the preset value.
Page 127 [Tech. Rep. Mode Tech. Rep. Choice 1/2] Touch Panel Display Highlighted Setting (The default is Leading Edge Erase Select whether to enable (“Yes”) or disable (“No”) the leading edge erase. Trailing Edge Erase Select whether to enable (“Yes”) or disable (“No”) the trailing edge erase.
Page 128 [Tech. Rep. Mode Tech. Rep. Choice 2/2] Touch Panel Display Setting (The default is Highlighted Function Limit Select whether to limit (“ON”) the functions that can be set on the control panel or not (“OFF”). Functions that can be set are lim- ited to the number of copies to be made, paper size, zoom ratio, and exposure level only.
Page 129: System Input
(3) System Input • This function allows the Tech. Rep. to change the fixed zoom ratios, set the paper size, define the marketing area, configure for the Key Counter, and input the telephone num- ber. [Tech. Rep. Mode Tech. Rep. Choice] Touch Panel Display Operation Change Fixed Zoom...
Page 130: Counter
(4) Counter • This function shows the counts of the various counters, thus aiding the Tech. Rep. in per- forming service jobs. <Setting Procedure> 1. Select [Counter]. 2. Select the desired counter function. 3. Clear or set the count according to the instructions given on the screen. <Clearing All Counts of a Counter Type at Once>...
Page 131 [Tech. Rep. Mode Counter] Touch Panel Display Operation Shows the number of misfeeds that have occurred in different parts of the copier system including MCBJ (system, copier only, ADF). <Jam Counter 1/3> Display Description Display Description MCBJ Misfeed occurrence No. of misfeeds that (System) rate of the entire Drawer...
Page 132: Counter
[Tech. Rep. Mode Counter] Touch Panel Display Operation <Jam Counter 3/3> Display Description Display Description No. of misfeeds that No. of misfeeds that Trans- occurred at the trans- Exit occurred at the exit port port section of the section of the ADF No.
Page 133 [Tech. Rep. Mode Counter] Touch Panel Display Operation Trouble Shows the number of malfunctions that have occurred in different parts of the copier system. <Trouble Counter 1/5> Malfunction Malfunction Location Location Code Code C000X Lower Drive C0070/1 Toner Hopper Motor Motor C001X Upper Drive...
Page 134 [Tech. Rep. Mode Counter] Touch Panel Display Operation Trouble <Trouble Counter 5/5> Malfunction Code Location C0b7X Sorter (Punch) C0d00 Front/Rear Guide C0d20 Dup Storage C0d5X Dup Drive Motor <Clearing a Count> Using the key, highlight the count to be cleared, then press the Clear key.
Page 135 [Tech. Rep. Mode Counter] Touch Panel Display Operation Port/option Shows the frequency of use of each of the different parts of the copier including options to serve as a guideline for the mainte- nance time for the Tech. Rep. <Port/Option 1/3> Display Description Display...
Page 136 [Tech. Rep. Mode Counter] Touch Panel Display Operation Auto CPU Reset Shows whether a CPU overrun has occurred in different CPU- mounted boards which are monitored by the watchdog function. Display Description Display Description MSC/ PWB-A AFR-12/AF-5 Panel (PWB-A) Master PWB-A Sorter S-106/ST-104...
Page 137 (5) I/O Check • This function is used to check the sensors and boards when a paper misfeed or malfunc- tion occurs, thereby locating the fault. [Tech. Rep. Mode I/O Check] Touch Panel Display Operation IC Port Data Check Shows the states of the I/O ports when the copier is in stand-by. With the output ports, the change of the data in the port allows an operation check of electrical components to be performed.
Page 138: I/O Check
[Tech. Rep. Mode I/O Check] Touch Panel Display Operation Memory Check Touching the Memory Check key causes the copier to automati- cally check the ROM/RAM on Master Board PWB-A. Result Display Action Normal “Memory check com- Turn OFF, then ON, the pleted.
Page 139 (7) RD Mode [Tech. Rep. Mode Last Trouble] Touch Panel Highlighted Setting (The default is Display RD Mode Make the initial settings of the copier for the Data Terminal. ID Code Entering a 7-digit ID code from the 10-Key Pad enables making the following settings.
Page 140: Rd Mode
[Tech. Rep. Mode RD Mode] Touch Panel Setting Display RD Mode ............Maintenance .
Page 141: Accessory Test
(8) Accessory Test • This function is used to make an operation check and adjustments of the ADF and Sorter or Staple Sorter. [Tech. Rep. Mode Accessory Test] Touch Panel Setting (The default is Highlighted Display ADF Check Enables the operation check and adjustments to be performed for the document feeder.
Page 142 [Tech. Rep. Mode Accessory Test] Touch Panel Setting Display Doc. Stop Posi- Adjusts the document stop position in different operating modes of the tion Set ADF. 1-Sided 2in1 Space in between origs. 2-Sided Auto Feeder 2 in 1 Regist Loop Setting 43 ........
Page 143: Level History
(9) Level History • This function is used to show and set the various level histories which were changed according to the operating conditions of the copier and user requirements. [Tech. Rep. Mode RD Mode] Touch Panel Setting Display Level History The touch of the Level History key will show the various level histories as detailed below.
Page 144: Machine Status
(10) Machine Status • This function shows the codes of isolated malfunctions which are currently present. This screen is also accessible by touching the wrench mark shown at the bottom left corner of the Basic screen under normal operating conditions. [Tech.
Page 145: Security Mode
SECURITY MODE • This mode is used to set the counter and copy vender. 36-1. Security Mode Setting Procedure <Setting Procedure> 1. Show the Service Mode Menu on the Touch Panel and then press the following keys in this order. →...
Page 146: 36-2.Security Mode Function Tree
36-2. Security Mode Function Tree Security Mode 1/2 Plug-In Counter Key Counter Count Size Counter Total Counter Security Mode Vender Mode Copy Kit Counter Security Mode 2/2 Copy Kit 36-3. Setting in the Security Mode [Security Mode Menu] Touch Panel Display Setting (The default is Highlighted Plug-In Counter...
Page 147 Touch Panel Display Highlighted Setting (The default is Total Counter Select the conditions (paper size and 2-sided copying) by which the Total Counter count is increased. 1 count per 1 copy cycle Mode 0 Mode 1 Multiple count-up according to paper size and 2-sided copying Mode 2 Multiple count-up according to paper size and...
Page 148 [Security Mode Menu] Touch Panel Display Highlighted Setting (The default is Vendor Mode Make the display setting according to the type of the optional ven- dor mounted on the copier. (Japan only) Disables the Copy Kit counter. Key Counter Coin Vendor Card NOTE Select “Key Counter.”...
Page 149: Factory Setting
FACTORY SETTING • Factory Setting is used to make adjustments at the factory. 37-1. Factory Setting Menu Screen 1149O424CA 37-2. Factory Setting Function Setting Procedure <Setting Procedure> 1. Show the Service Mode Menu on the Touch Panel and press the following keys in this order.
Page 150: 37-3.Factory Setting Function Tree
37-3. Factory Setting Function Tree Adjust 1/2 Lens Focus Lens Full Size Position Mirror Full Size Position Feed Direction Mag. Ratio Scan Regist Full Size Scan Regist Reduction Adjust Adjust 1/2 Book B-Scan Regist Scan Regist Enlargement Leading Edge Erase Adjust Trailing Edge Erase Adjust Factory Setting...
Page 151 - Components Energized in “Function” - Component Main Drive Motor — Fan Motors — Toner Replenishing Motor — — — — — — Paper take-up — — — — — — — Scan — — — — Exposure Lamp — —...
Page 152: Adjust
(2) Adjust • This function is used to adjust the optical system before shipment from the factory and must not be run except when the RAM Board has been replaced with a new one or mem- ory cleared. Further, when the RAM Board has been changed or memory cleared, enter the factory settings indicated on the Adjust Mode label affixed to the inside of the Front Door.
Page 153 [Factory setting Adjust] Touch Panel Display Operation Scan Regist Corrects the amount of offset along the leading edge in a reduction Reduction mode by varying the Synchronizing Roller start timing. Setting 30 ............70 –5.6mm ...... ±0......+5.6mm Description (Smaller) (Greater) Book B-Scan Corrects registration in Book B-Scan by varying the Synchronizing...
Page 154 EP3010 DIS/REASSEMBLY, ADJUSTMENT 18605...
Page 155 Safety Precautions for Inspection and Service When performing inspection and service procedures, observe the following precautions to prevent accidents and ensure utmost safety. Depending on the model, some of the precautions given in the following do not apply. Different markings are used to denote specific meanings as detailed below. Indicates a potentially hazardous situation which, if not avoided, WARNING could result in death or serious injury.
Page 156 4. Handle the power cord with care and never use a multiple socket. • Do not brake, crush or otherwise damage the power cord. Placing a heavy object on the power cord, or pulling or bending it may damage it, resulting in a possible fire or electric shock.
Page 157 CAUTION 1. Precautions for Service Jobs • A toothed washer and spring washer, if used originally, must be reinstalled. Omitting them may result in contact failure which could cause an electric shock or fire. • When reassembling parts, make sure that the correct screws (size, type) are used in the correct places.
Page 158 5. Precautions for Laser Beam (Products Employing Laser Only) • Removing the cover marked with the following caution label could lead to possi- ble exposure to the laser beam, resulting in eye damage or blindness. Be sure to unplug the power cord before removing this cover. •...
Page 159 Other Precautions • To reassemble the product, reverse the order of disassembly unless otherwise specified. • While the product is energized, do not unplug or plug connectors into the circuit boards or harnesses. • The magnet roller generates a strong magnetic field. Do not bring it near a watch, floppy disk, magnetic card, or CRT tube.
Page 160 Used Batteries Precautions (ALL Areas) CAUTION Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer’s instructions. (Germany only) VORSICHT! Explosinsgefahr bei unsachgemäßen austausch der batterie. Ersatz nur durch denselben oder einen vom hersteller empfohlenen ähnlichen typ.
Page 161 CONTENTS 1. SERVICE INSTRUCTIONS ................D-1 1-1. INSTRUCTIONS FOR HANDLING THE PWBs WITH MOS ICs ..... D-1 1-2. HANDLING OF THE PC DRUM .............. D-1 1-3. PARTS WHICH MUST NOT BE TOUCHED ........... D-4 Screws ..................... D-4 Variable Resistors on Board ............D-4 Other Screws ...................
Page 162 Cleaning of the Upper Fusing Roller ..........D-40 Cleaning of the Upper Paper Separator Fingers ......D-40 Cleaning of Fusing Thermistor 1, 2 ..........D-41 Cleaning of the Fusing Thermoswitch ..........D-41 Removal of the Brush Roller ............D-41 Cleaning of the Brush Roller ............D-41 (10) Removal of the Lower Fusing Roller ..........
Page 163: Service Instructions
SERVICE INSTRUCTIONS 38-1. INSTRUCTIONS FOR HANDLING THE PWBs WITH MOS ICs The following precautions must be observed when handling P.W. Boards with MOS (Metal Oxide Semiconductor) ICs. During Transportation/Storage: • During transportation or when in storage, new P.W. Boards must not be indiscriminately removed from their protective conductive bags.
Page 164 If, however, the surface is contaminated with fingerprints, clean it using the following proce- dure. 1. Place the PC Drum into one half of its container. 1076D001 2. Gently wipe the residual toner off the surface of the PC Drum with a dry, Dust-Free Cotton Pad. A.
Page 165 NOTES • The Organic Photoconductor Drum is softer than CdS and Selenium Drums and is there- fore susceptible to scratches. • Even when the PC Drum is only locally dirtied, wipe the entire surface. • Do not expose the PC Drum to direct sunlight. Clean it as quickly as possible even under interior illumination.
Page 166: Parts Which Must Not Be Touched
38-3. PARTS WHICH MUST NOT BE TOUCHED (1) Screws Purpose of Application of Red Paint Red paint is applied to the screws which cannot be readjusted, set, or reinstalled in the field. The basic rule is not to remove or loosen the screws to which red paint is applied. In addi- tion, be advised that, if two or more screws are designated as those which must not be touched on a single part, only one representative screw may be marked with red paint.
Page 167: Doors, Covers, And Exterior Parts: Identification And Removal Procedures
DISASSEMBLY/REASSEMBLY 39-1. DOORS, COVERS, AND EXTERIOR PARTS: IDENTIFICATION AND REMOVAL PROCEDURES 1149D056AA 1149D057AA...
Page 168 Part Name Removal Procedure Swing down No. 1. → Remove one screw that secures the Front Door Belt. → Remove two screws that secure the Front Door (only on one side). → Slide the Door to the side from which the screws have been removed.
Page 169 Part Name Removal Procedure Swing down No. 1. → Release and swing up the Upper Half of Upper Left Cover the copier. → Remove four screws that secure the Upper Left Cover. Swing down No. 1. → Release and swing up the Upper Half of Middle Front Left the copier.
Page 170: Removal Of Pwbs
39-2. REMOVAL OF PWBs • When removing a PWB, first go over “PRECAUTIONS FOR HANDLING THE PWBs” contained in SWITCHES ON PWBs and use the removal procedures given on the next page. • Replacement of a PWB may call for readjustments or resetting of particular items. •...
Page 171 Symbol Part Name Removal Procedure Open 1. → Release and swing up the Upper Half of PWB-A Master Board the copier. → Remove 19. Open 1. → Release and swing up the Upper Half of PWB-C Power Supply Board the copier. → Remove 17, 18, and 19. → Remove four PWB-D Noise Filter Board screws that secure the Power Supply Unit Cover.
Page 172: Belt Installations
39-3. BELT INSTALLATIONS • Rear View Drive/Suction Unit 1151D052AB Paper Take-Up Unit 1149D060AA D-10...
Page 173: Paper Take-Up/Transport Sections
39-4. PAPER TAKE-UP/TRANSPORT SECTIONS (1) Removal of the Paper Take-Up Unit 1. Remove the Multi Bypass Table. 2. Slide out the 1st and 2nd Drawers. 1149D002AA 3. Remove the Upper Rear, Rear, and Lower Rear Covers. 4. Remove the 1st and 2nd Drawer Paper Take-Up Motors (two screws each).
Page 174: Removal Of The Paper Take-Up Roll Assy
9. Remove the paper take-up unit (six screws). 1149D008AA (2) Removal of the Paper Take-Up Roll Assy 1. Remove paper guide plates A and B (two screws each). 1149D009AA 2. Remove paper guide plate C (two springs). 1149D010AA 3. Remove the Paper Separator Roll Assy (one screw).
Page 175: Cleaning Of The Paper Take-Up Roll, Feed Roll, And Separator Roll
5. Disassemble the Paper Take-Up Roll/Feed Roll Assy. 1134D014AA Keep the lock pin for later use. (3) Cleaning of the Paper Take-Up Roll, Feed Roll, and Separator Roll 1. Remove each Paper Take-Up Roll/Feed Roll Assy. 2. Remove each Paper Separator Roll Assy. 3.
Page 176: Disassembly Of The Suction Unit
(5) Disassembly of the Suction Unit 1. Remove the four Suction Drive Rolls and six bush- ings by pulling them in the direction of the arrow. 1151D004AA 2. Snap off the three E-rings from the Suction Drive Unit. 3. Remove the gear and bushings. 1139D094AA 4.
Page 177: Disassembly Of The Multi Bypass Table
(6) Disassembly of the Multi Bypass Table 1. Remove the Right Lower Rear Cover (two screws). 1149D014AA 2. Remove the four screws that secure the Right Door; then, remove the Right Door. 1149D015AA 3. Remove three screws and the Large Cover. 4425U408AA 4.
Page 178 1149D016AB 6. Remove four screws and the Multi Bypass Table. 7. Unplug the Multi Bypass Table connector. 1139D240AA 8. Remove one screw and the Multi Bypass Table. 1139D225AA 9. Unplug one connector. 1149D017AA 10. Remove two screws and the Clutch Mounting Bracket.
Page 179 12. Remove two screws and the Lower Guide. 1139D102AA 13. Remove four screws and the Separator Guide Plate Unit. 1139D103AA NOTE When reinstalling the Separator Guide Plate Unit, press the parts shown on the left up against the copier frame (both at front and rear). 1139D104AA 14.
Page 180 16. Snap off one C-clip and remove the Separator Roll Assy. 1139D107AA 17. Remove three screws and the Solenoid Mounting Bracket. 1139D108AA 18. Unplug one solenoid connector. 19. Unplug one photosensor connector and remove the harness from the clamp. 1139D109AA NOTE When reinstalling the Solenoid Mounting Bracket, make sure that the Solenoid is in the deenergized...
Page 181 21. Snap off the three C-clips to remove the Paper Feed Roll. 1139D112AA 22. Snap off one C-clip and remove the Paper Take-Up Roll. 1139D113AA D-19...
Page 182: Optical Section
39-5. OPTICAL SECTION (1) Removal of the Lens Drive Cable 1. Remove two screws and the Optical Section Cover. 1139D114AA 2. Remove three screws and the Lens Cover. 1139D115AA 3. Remove two screws, two clamps and the Lens Motor Unit. 1139D116AA 4.
Page 183: Winding Of The Lens Drive Cable
(2) Winding of the Lens Drive Cable 1. Hold the Cable Drive Gear in position with its Bead at the bottom. 1139D119AA 2. Wind the shorter length of the Cable three turns clockwise around the Cable Drive Gear, working from the back to the front side. Then tape it. 1139D120AA 3.
Page 184: Removal Of The Scanner Drive Cable
6. Temporarily secure the longer length of the Cable to the Cable Fixing Bracket, ensuring a distance of 5 ± 2 mm for the dimension shown on the left. 1139D124AA 7. Wind the shorter length of the Cable around the Pulley which is nearer to the Cable Drive Gear.
Page 185 3. Unhook the spring and remove the length of the cable on the right (looking at the copier from the rear). 1139D129AA 4. Move the 2nd/3rd Mirrors Carriage toward the Scanner Drive Gear so that the cable slacks off and then remove the length of cable on the left (looking at the copier from the rear).
Page 186: Winding Of The Scanner Drive Cable
(4) Winding of the Scanner Drive Cable Remark Whenever the Scanner Drive Cable has been rewound, be sure to make the “Adjustment of the Scanner/Mirrors Carriage Position.” Pulley B Pulley A Scanner Drive Gear Pulley C 1149D047AB 1. (With reference to the center of the entire length of the cable) Wind one length of the cable 5 times counterclockwise around the Pulley, starting with the end of the D-cut on the pulley shank and work-...
Page 187 4. Hook the length of cable on the left (looking at the copier from the rear), around Pulleys C and B and secure it to the frame. 1149D041AB 5. Peeling off the tape, pull the length of cable on the right (looking at the copier from the rear) and hook it onto Pulleys A and B.
Page 188: Removal Of The Scanner
(5) Removal of the Scanner Turn the Scanner Drive Gear to move the Scanner to the right side of the copier. Then, remove three screws and the Scanner. NOTE Mount the Scanner so that it touches against the Posi- tioning Plate of the Shaft Stand. 1151D019AA (6) Cleaning of the Exposure Lamp 1.
Page 189: Cleaning Of The Lens And 4Th Mirror
(8) Cleaning of the Lens and 4th Mirror Gently dust off the surface of the Lens and 4th Mirror by using a dry soft cloth. NOTE An alcohol-dampened cloth may be used if the Lens or Mirror is seriously contaminated. 1139D147AA (9) Cleaning of the Optical Section Cooling Fan Filter 1.
Page 190: Imaging Unit
39-6. IMAGING UNIT (1) Disassembly, Cleaning, and Replacement of the Imaging Unit Changing the Starter 1. Remove the Imaging Unit from the copier. 2. Remove the Imaging Unit Cover (two screws). NOTE • When removing the Imaging Unit, do not hold onto the Main Erase Lamp end (as a deformed PC Drum Paper Separator Finger results).
Page 191 Replacement of the Toner Scattering Prevention Plate 6. Remove one screw, one shoulder screw and the Toner Scattering Prevention Plate. 1139D153AA 7. Tilt the Developing Unit to remove the developer. 1139D154AA Cleaning of the Doctor Blade 8. Clean the Surface of Doctor Blade using a brush or vacuum cleaner.
Page 192 Applying Toner to Cleaning Blade Apply toner to the entire surface of the Cleaning Blade. (Do not forget to coat the surfaces on both ends.) Install the PC Drum. Apply a thin coat of toner to the PC Drum. Turn the PC Drum 1/2 turns backward, then turn it one complete turn forward. Cleaning of the PC Drum Paper Separator Fingers and AIDC Sensor 12.
Page 193 16. Remove the Synchronizing Roller. 17. Using a brush, whisk the dust and dirt off the Filter. 1139D156AA Cleaning of the Upper and Lower Synchronizing Rollers 18. Using a brush or a soft cloth dampened with alco- Upper Synchronizing Roller hol, clean the Upper and Lower Synchronizing Rollers.
Page 194: Cleaning Of Main Erase Lamp
Antispill Plate 1149D067AA 21. Refit the parts to the Imaging Unit and reinstall the Imaging Unit in the copier. 22. Load fresh starter and make the ATDC adjustment. 1139D020AA (2) Cleaning of Main Erase Lamp 1. Remove the Imaging Unit. 2.
Page 195: Cleaning Of Image Erase Lamp
(3) Cleaning of Image Erase Lamp 1. Remove Master Board (four screws). 1149D023AA 2. Insert Master Board into the copier to secure it. 1149D024AA 3. Go to the rear of the copier and unplug one Image Erase Lamp connector. 1149D025AA 4.
Page 196: Pc Drum Charge Corona/Image Transfer Corona Unit
39-7. PC DRUM CHARGE CORONA/IMAGE TRANSFER CORONA UNIT (1) Cleaning of the PC Drum Charge Corona Housing 1. Remove the Imaging Unit. 2. Remove Main Erase Lamp (two screws). 3. Remove one screw and PC Drum charge Corona Unit. 4. Press the Mesh Holder on the front of the Corona Unit in the direction of arrow A to remove the Grid Mesh.
Page 197: Cleaning Of The Pc Drum Charge Corona Grid Mesh
(2) Cleaning of the PC Drum Charge Corona Grid Mesh Blow all foreign matter off the Grid with a blower brush. NOTE If the blower brush is not effective in cleaning the Grid, use a soft cloth dampened with alcohol to clean seri- ous contamination.
Page 198: Cleaning Of The Image Transfer/Paper Separator Coronas Housing
(5) Cleaning of the Image Transfer/Paper Separator Coronas Housing 1. Remove the four Paper Guides. 2. Remove the two End Caps. 3. Remove the Image Transfer and Paper Separator Corona Wires. NOTE When removing the Wire, unhook the spring end first and use care to prevent breaking and deformation.
Page 199: Fusing Unit
39-8. FUSING UNIT (1) Removal of the Fusing Unit 1. Remove one screw and the Ground Wire of the Fusing Unit. 1151D038AA 2. Unplug the Fusing Heater Lamp connector and remove the wires from the clamp. 1151D007AA 3. Unplug the Fusing Thermistor connectors and remove the wires from the two clamps.
Page 200: Cleaning Of The Pre-Fusing Guide Plate
(2) Cleaning of the Pre-Fusing Guide Plate Using a soft cloth dampened with alcohol, wipe clean the Guide Plate. 1139D190AA (3) Removal of the Upper Fusing Roller 1. Remove two screws and the Fusing Unit Front Cover. 2. Remove two screws and the Fusing Unit Upper Cover.
Page 201 5. Remove the rear lamp harness and harness clamps (four). 6. Remove the mounting bracket (one screw). 1149D029AA 7. Remove the Fusing Thermoswitch (two screws). 1149D030AA 8. Remove three Cord Holders of Fusing Thermistor 1, 2. 9. Remove one screw and the Fusing Thermistor. 1149D031AA 10.
Page 202: Cleaning Of The Upper Fusing Roller
11. Remove two roller shaft fixing brackets and one Fusing Heater Lamp fixing bracket. 1149D032AA 12. Remove two C-clips. 13. Remove one spur gear. 14. Remove two bushings. 15. Remove the Upper Fusing Roller. 1149D033AA (4) Cleaning of the Upper Fusing Roller Using a soft cloth dampened with alcohol or silicone oil, wipe clean the Upper Fusing Roller.
Page 203: Cleaning Of The Fusing Thermoswitch
(6) Cleaning of Fusing Thermistor 1, 2 Using a soft cloth dampened with alcohol or silicone oil, wipe clean the Thermistor. 1151D039AA (7) Cleaning of the Fusing Thermoswitch Using a soft cloth dampened with alcohol or silicone oil clean the Fusing Thermoswitch. 1149D068AA (8) Removal of the Brush Roller 1.
Page 204: Removal Of The Lower Fusing Roller
(10) Removal of the Lower Fusing Roller 1. Turning it in the direction of the arrow, remove the Lower Separator Fingers Unit. 1139D201AA 2. Remove the Lower Fusing Roller NOTE • Different types of pressure springs are used at the front and rear ends of the Fusing Unit.
Page 205: Disassembly Of The Exit/Duplex Switching Unit
(13) Disassembly of the Exit/Duplex Switching Unit 1. Remove two screws and the Upper Guide Plate. 1139D205AA 2. Remove two screws and the Exit/Duplex Switching Unit. 3. Unplug one connector. 1139D206AA 4. Remove two screws and the Cover. 1139D207AA 5. Remove the Solenoid Cover by unhooking its catches at three places.
Page 206 8. Remove one screw and the Solenoid Unit. 1139D210AA NOTE Make the adjustment with If the solenoid has been removed from the Solenoid the Lever in contact with Unit, make the adjustment shown on the left with the the metal plate. Solenoid Unit installed in the Exit/Duplex Switching Unit.
Page 207 12. Remove one screw and the Photoswitch Mounting Bracket. 13. Remove two screws and the Exit Rolls Mounting Bracket Unit. 1139D215AA Rear NOTE When reinstalling the Exit Rolls Mounting Bracket Unit, make sure that the Reinforcement Plate Unit is in con- tact with the Exit Rolls Mounting Bracket Unit as shown on the left.
Page 208: Adjustment
ADJUSTMENT 40-1. JIGS AND TOOLS USED Important • When adjusting the positions of the Scanner and Mirrors Carriage, use Jigs numbered • When adjusting the gap between the Doctor Blade and Sleeve Roller, use Jigs numbered • When adjusting the position of PC Drum Paper Separator Fingers, use Jigs numbered Front Door Interlock Scanner Positioning jig Switch Actuating Jig...
Page 209 40-2.ADJUSTMENT REQUIREMENTS LIST Ref. Adjustment Item Requirements Adjusting Point Page Optimum Exposure Setting Kodak Gray Scale: Control panel in the Manual Exposure no image of the 1st step, D-50 Mode faint image of the 2nd step Optimum Exposure Setting Control panel in the Auto Exposure D-49 Mode...
Page 210: Adjustment Of Switches
40-3. ADJUSTMENT OF SWITCHES (1) Adjustment of Front Door Interlock Switch 1. Open the Front Door. 2. Loosen two screws that secure the Front Door Interlock Switch Actuating Plate to the Front Door. 1174M023AA 3. Move the Switch Actuating Plate back and forth to meet the requirements below.
Page 211: Electrical/Image Adjustments
40-4. ELECTRICAL/IMAGE ADJUSTMENTS (1) Adjustment of the Optimum Exposure Setting in the Auto Mode Important • This adjustment must be made before the optimum exposure setting in the Manual mode is adjusted. 1. Place about five sheets of A3 or 11" × 17" paper on the Original Glass and lower the Original Cover.
Page 212: Adjustment Of The Optimum Exposure Setting In The Manual Mode
(2) Adjustment of the Optimum Exposure Setting in the Manual Mode Requirement • When the manual exposure setting is at the central indication, no image of step no. 1 of a Kodak Gray Scale should be produced on the copy, but a faint image of step no. 2 should be produced.
Page 213: Adjustment Of The Atdc Sensor
(3) Adjustment of the ATDC Sensor Important In the following cases, carry out ATDC Adjustment: • When a new Imaging Unit is used. • When new Starter is loaded into a Used Imaging Unit. 1. Load the starter. 1139D020AA 2. On the control panel, press the User Mode key, Meter Count key, Stop key, 10-keys “0”, 10-keys “0”, Stop key, 10-keys “0”, and 10-keys “1”, in that order, to set the copier into the Tech.
Page 214: Adjustment Of The Aperture Blades
(4) Adjustment of the Aperture Blades Requirement • There should be no dark or light bands running in the feeding direction on copies pro- duced. (Adjust to obtain the mean image density for all areas.) Important • If dark and light bands running in the feeding direction occur on copies, make this adjust- ment after checking the following.
Page 215: Adjustment Of The Multi Bypass Table Reference Position
(5) Adjustment of the Multi Bypass Table Reference Position Requirement • Ready a test chart (A3 or 11" × 17") as shown on the left. Draw a line on the chart at a point 20 mm from the right edge as shown. •...
Page 216: Adjustment Of The 1St/2Nd Drawer Reference Position
(6) Adjustment of the 1st/2nd Drawer Reference Position Requirement • Ready a test chart (A3 or 11” × 17”) as shown on the left. Draw a line on the chart at a point 20 mm from the right edge as shown. •...
Page 217: Adjustment Of The Zoom Ratio In The Feeding Direction ("A3 Feed Direction Mag. Ratio" Of Adjust Mode
(7) Adjustment of the Zoom Ratio in the Feeding Direction (“A3 Feed Direction Mag. Ratio” of Adjust Mode) • Prepare a GTC-003 Chart and, using part A shown in the illustration on the left, adjust to meet the fol- lowing specifications on the copy. Zoom Ratio Width A (mm) Full Size (×...
Page 218 7. Using the “ ” or “ ” key, change the value so that width A falls within the specified range. NOTE If width A on the copy is smaller than 185.5, touch the “ ” key. If width A on the copy is greater than 301.5, touch the “...
Page 219: Adjustment Of The Leading Edge Registration
(8) Adjustment of the Leading Edge Registration Full Size Requirement • Ready a test chart (A3 or 11” × 17”) as shown on the left. Draw a line across the test chart at a point 20 mm from the leading edge and use it as the refer- ence line.
Page 220 5. Touch “Adjust” to open the “Adjust 1/2” menu. 6. Touch “ ” to highlight “A4 Scan Regist Full Size.” 1173D019CA 7. Using the “ ” or “ ” key, change the value so that width A falls within the specified range. NOTE If width A on the copy is smaller than 18.5, touch the “...
Page 221 Reduction 1. After the leading edge registration in the full size mode has been adjusted, make two single copies in a reduction mode (×0.500) and check for leading edge registration on the second copy. 1139D042AB 2. If the registration does not meet the requirement, go to the control panel and press the User Mode key, Meter Count key, Stop key, 10-keys “0”, 10- keys “0”, Stop key, 10-keys “0”, and 10-keys “1”, in...
Page 222 Book Second Page Important • This adjustment must be made after the “Adjustment of the Leading Edge Registration in the Reduction Mode” has been made. 1. Prepare a chart as shown on the left. • Reference line: 20 mm (B = C) •...
Page 223 Enlargement 1. After the leading edge registration for the Book Second Page has been adjusted, make two single copies in an enlargement mode (× 2.000) and check for leading edge registration on the second copy. 1139D037AB 2. Press the User Mode key, Meter Count key, Stop key, 10-keys “0”, 10-keys “0”, Stop key, 10-keys “0”, and 10-keys “1”, in that order, on the control panel to set the copier into the Tech.
Page 224: Adjustment Of The Image Leading Edge Erase Width
(9) Adjustment of the Image Leading Edge Erase Width Requirement • Ready a test chart (A3 or 11" × 17") as shown on the left. Paint a 20 mm-long rectangle in black at the center of the test chart along its leading edge as shown.
Page 225 7. Using the “ ” or “ ” key, change the value so that the erase width falls within the specified range. NOTE If the width on the copy is less than 1.0 mm, touch the “ ” key. If the width on the copy is more than 6.5 mm, touch the “...
Page 226: Adjustment Of The Image Trailing Edge Erase Width
(10) Adjustment of the Image Trailing Edge Erase Width Requirement • Ready a test chart (A3 or 11”x17”) as shown on the left. • Paint a 20mm-long rectangle in black at the center of the test chart along its trailing edge as shown. Adjust so that the erase width along the trailing edge of the painted area measures 0.5 to 5.5 mm.
Page 227 7. Using the “ ” or “ ” key, change the value so that the erase width falls within the specified range. NOTE If the erase width on the copy is less than 0.5 mm, touch the “ ” key. If the erase width on the copy is more than 5.5 mm, touch the “...
Page 228: Adjustment Of The Image Erase Lamp Position
(11) Adjustment of the Image Erase Lamp Position Requirement +0.5 • Image erase width: Within 0.5 –0 Important • This adjustment must be made after the reference positions of the Multi Bypass Table and 1st and 2nd Drawers have been adjusted. 1.
Page 229: Other Adjustments
40-5. OTHER ADJUSTMENTS (1) Adjustment of the Scanner/Mirrors Carriage Position Requirement • With the Scanner positioned correctly with reference to the upper copier frame, there should be no gap between the Scanner/Mirrors Carriage and the Scanner/Mirrors Car- riage Positioning Jig. 1.
Page 230: Adjustment Of The Gap Between The Doctor Blade And Sleeve Roller
(2) Adjustment of the Gap Between the Doctor Blade and Sleeve Roller Requirement • The gap between the Doctor Blade and the Sleeve Roller should be 0.35 mm ± 0.05 mm. Important • Cover the PC Drum with the Drum Cloth to prevent it from being scratched. 1.
Page 231: Adjustment Of The Pc Drum Paper Separator Fingers Position
(3) Adjustment of the PC Drum Paper Separator Fingers Position Requirement • The gap between the PC Drum and the PC Drum Paper Separator Fingers should be 1.0 ± 0.5 mm when the Separator Solenoid is in the deenergized position. Important •...
Page 232: Adjustment Of The Original Size Detecting Board
(4) Adjustment of the Original Size Detecting Board Important • This adjustment must be made after the Original Size Detecting Board has been replaced. 1. Lower the Original Cover with no paper on the Original Glass. 1139D228AA 2. On the control panel, press the User Mode key, Meter Count key, Stop key, 10-keys “0”, 10-keys “0”, Stop key, 10-keys “0”, and 10-keys “1”, in that order, to set the copier into the Tech.
Page 233: Miscellaneous
MISCELLANEOUS 41-1. INSTALLATION OF ORIGINAL SIZE DETECTING SENSORS FD3/CD2 (OPTION; STANDARD FOR 200V AREAS) 1. Remove the Original Scales and Original Glass. 2. Install the Original Size Detecting Sensors (option). (FD3) • Remove the harness cover (one screw). • Secure FD3 in position (one screw). •...
Page 234: Installation Of The Plug-In Counter Mounting Bracket (Option
41-2. INSTALLATION OF THE PLUG-IN COUNTER MOUNTING BRACKET (OPTION) 1. Remove the Middle Right Cover. 1149D020AA 2. Remove the Counter Cover. 3. Remove the Upper Right Cover. 4. Remove the Right Cover. 1139D061AA 5. Connect the Plug-In Counter Connector. 1139D063AA 6.
Page 235 EP3010 TROUBLESHOOTING 10794...
Page 236 CONTENTS 1. INTRODUCTION ..................... T-1 1-1. General Precautions ................T-1 1-2. How to Use This Book ................T-1 1-3. Reading the Text ..................T-1 2. I/O PORT CHECK ................... T-2 2-1. Controlled Parts Check Procedure ............T-2 2-2. I/O Port Check List ................... T-5 3.
Page 237 (10) C0910: 2nd Drawer Upward Motion Failure C0914: 2nd Drawer Paper Lift-Up Motor M14’s Failure to Turn C0920: 1st Drawer Upward Motion Failure C0924: 1st Drawer Paper Lift-Up Motor M13’s Failure to Turn ..T-63 (11) C0900: 3rd Drawer Upward Motion Failure C0904: 3rd Drawer Paper Lift-Up Motor M24’s Failure to Turn C0950: 4th Drawer Upward Motion Failure C0954: 4th Drawer Paper Lift-Up Motor M25’s Failure to Turn ..
Page 238: How To Use This Book
INTRODUCTION 42-1. General Precautions 1. When servicing the copier with its covers removed, use utmost care to prevent your hands, clothing, and tools from being caught in revolving parts including the chains and gears. When servicing the copier with the Lower Rear Cover removed, be sure to install the jig.
Page 239: I/O Port Check
I/O PORT CHECK 43-1. Controlled Parts Check Procedure To allow the Tech. Rep. to easily and safely determine whether a particular controlled part is fully operational, this copier provides the following provision: checking the data of the I/O port of the board IC with the copier in the standby state (including a misfeed, malfunction, and closure failure condition) allows the Tech.
Page 240 <Controlled Part Check Procedure by Changing Input Port Data> Example When a paper misfeed occurs in the paper take-up section of the copier, 1st Drawer Paper Take-Up Sensor PC55 is considered to be responsible for it. Procedure 1. Remove the sheet of paper misfed. 2.
Page 241 <Controlled Part Check Procedure by Changing Output Port Data> Example When a manual paper misfeed occurs, Manual Feed Paper Take-Up Clutch CL51 is consid- ered to be responsible for it. Procedure 1. Remove the sheet of paper misfed and reset the misfeed. 2.
Page 242: I/O Port Check List
43-2. I/O Port Check List <Port Check Screens> • The following screens are displayed in the standby mode but may not always be as shown below because some port data are undefined. 1173T019CA 1173T023CA 1173T020CA 1173T024CA 1173T021CA 1173T025CA 1173T022CA...
Page 243 <I/O Port Check List> Copier The shaded areas of the following table indicate that the output check cannot be made by touching the Change key. Operation Charac- Dis- teristics/Panel Port CN/PJ Symbol Part/Signal Name play Display Page H or 1 L or 0 PC Drive Motor/REM IC4A...
Page 244 Operation Charac- Dis- teristics/Panel Port CN/PJ Symbol Part/Signal Name play Display Page H or 1 L or 0 Separator Solenoid IC4A BPA0 PJ7A-4 Exit/Duplex IC4A BPA5 PJ9A-10 Switching Solenoid Manual Feed Paper SL51 Take-Up Solenoid IC5A BPA2 ON (up) PJ14A-3 (UP) Manual Feed Paper Take-Up Solenoid...
Page 245 Operation Charac- Dis- teristics/Panel Port CN/PJ Symbol Part/Signal Name play Display Page H or 1 L or 0 Vertical Transport Paper not Paper PC64 IC3A APB6 PJ17A-8B Sensor present present Not at 1st Drawer Lift-Up PC65 IC3A APB1 upper upper PJ17A-2A Sensor limit...
Page 246 Operation Charac- Dis- teristics/Panel Port CN/PJ Symbol Part/Signal Name play Display Page H or 1 L or 0 Main Relay IC1A PJ12A-3 Exposure Lamp/AVR IC1A PJ36A-4 Main Erase Lamp 2/7/7 IC4A BPA1 PJ8A-8 Image Erase Lamp IC5A APB2 DC24V PJ13A-1 24V0 Image Erase Lamp IC5A...
Page 247 PF-206 Operation Charac- Dis- teristics/Panel Port CN/PJ Symbol Part/Signal Name play Display Page H or 1 L or 0 Vertical Transport Turn Turn per- IC1A — Motor inhibited mitted 3rd Drawer Paper Turn Turn per- IC1A — Take-Up Motor inhibited mitted 4th Drawer Paper Turn...
Page 248 Operation Charac- Dis- teristics/Panel Port CN/PJ Symbol Part/Signal Name play Display Page H or 1 L or 0 4th Drawer Paper Paper not Paper PC24 IC1A PJ9A-12 Empty Sensor present present 3rd Drawer Set Sen- Out of PC25 IC1A In position PJ8A-9B position 4th Drawer Set Sen- Out of...
Page 249 PF-112 Operation Charac- Dis- teristics/Panel Port CN/PJ Symbol Part/Signal Name play Display Page H or 1 L or 0 Vertical Transport Turn Turn per- IC1A — Motor inhibited mitted 3rd Drawer Paper Turn Turn per- IC1A — Take-Up Motor inhibited mitted Main Tray Elevator IC1A...
Page 250 Operation Charac- Dis- teristics/Panel Port CN/PJ Symbol Part/Signal Name play Display Page H or 1 L or 0 Lower Right Door Out of PC18 IC1A In position PJ8A-5A Sensor position Not at 3rd Drawer Paper At upper PC19 IC1A upper PJ8A-12B Lift-Up Sensor limit...
Page 251 PF-6D/AD-11 Operation Charac- Dis- teristics/Panel Port CN/PJ Symbol Part/Signal Name play Display Page H or 1 L or 0 Vertical Transport Turn Turn per- IC1A — Motor inhibited mitted Duplex Unit Drive IC1G PJ6G-2 Motor Duplex Unit Drive When When IC1G PJ6G-1 Motor/lock signal...
Page 252: Paper Transport Failure
PAPER TRANSPORT FAILURE 3-1. Paper Misfeed When a paper misfeed occurs, the Touch Panel shows the corresponding message, mis- feed location and paper location. Blinking There is a misfeed at Light this location. There might be a sheet Steady of paper stopped at this Light location.
Page 253 <Misfeed Detecting Sensor Layout> When options are installed Paper Exit Sensor (PC30) Transport Roller Sensor (PC51) Paper Leading Edge Detecting Sensor (PC54) 1st Drawer Paper Take-Up Sensor (PC55) Vertical Trans- port Sensor (PC64) 2nd Drawer Paper Take-Up Duplex Unit Sensor (PC56) Vertical Transport Sensor...
Page 254: Misfeed Detection Types And Detection Timings
3-2. Misfeed Detection Types and Detection Timings • The following table lists the types of misfeed detection classified by the misfeed locations and their corresponding detection timings. Note For the misfeed detection types and detection timings in the options, see the Service Man- ual for the options.
Page 255 <Transport/Separator Misfeed> Type Detection Timing Trailing edge detection PC51 is not unblocked (H) even after the lapse of T seconds by Transport Roller (which varies for paper sizes) after the TRON signal has been Sensor PC51 input. Leading edge detec- PC54 is not blocked (L) even after the lapse of approx.
Page 256 3-3. Misfeed Troubleshooting Procedures (1) Copier Paper Take-Up Misfeed Relevant Electrical Parts • 1st Drawer Paper Take-Up Sensor PC55 • 1st Drawer Paper Take-Up Motor M11 • 2nd Drawer Paper Take-Up Sensor PC56 • 2nd Drawer Paper Take-Up Motor M12 •...
Page 257 Copier Paper Take-Up Misfeed Troubleshooting Procedure Symptom Step Check Item Result Action • Paper is not Does the paper being used Instruct the user to use the taken up at all. meet product specifications? paper that meets product specifications. • Paper is station- Is the paper curled, waved or Change the paper.
Page 258 (2) Transport/Separator Misfeed Relevant Electrical Parts • Transport Roller Sensor PC51 • Separator Solenoid (SL1) • Paper Leading Edge Detecting Sensor PC54 • Suction Fan Motor M3 • Paper Transport Clutch CL2 • High Voltage Unit HV1 • Synchronizing Roller Clutch CL1 •...
Page 259 Transport/Separator Misfeed Troubleshooting Procedure Symptom Step Check Item Result Action Paper is station- Is the paper curled, waved or Change the paper. Instruct the ary at the Syn- damp? user in how to store the paper. chronizing Roller. Does CL1 operate properly? Check the drive transmission Using the IC Port Data Check path.
Page 260 (3) Multi Bypass Misfeed Relevant Electrical Parts • Manual Feed Paper Empty Sensor PC31 • Master Board PWB-A • Manual Feed Paper Take-Up Solenoid SL51 • Manual Feed Paper Take-Up Clutch CL51 1173C03TAD T-23...
Page 261 Multi Bypass Misfeed Troubleshooting Procedure Symptom Step Check Item Result Action Paper is not Does PC31 operate properly? YES Replace PWB-A. detected. Using the IC Port Data Check Check the operation of the function, make an input port actuator of PC31. If it operates check on PWB-A (IC5A) properly, replace PC31.
Page 262: Fusing/Exit Misfeed
(4) Fusing/Exit Misfeed Relevant Electrical Parts • Paper Exit Sensor PC30 • Suction Fan Motor M3 • Master Board PWB-A 1173C21TAC T-25...
Page 263 Fusing/Exit Misfeed Troubleshooting Procedure Symptom Step Check Item Result Action Paper is station- Is the paper curled, waved or Change the paper. Instruct the ary before the damp? user in how to store the paper. Fusing Roller. Is the Fusing Guide Plate Clean, correct or replace the deformed or dirty? Fusing Guide Plate.
Page 264 (5) PF-206 Paper Take-Up Misfeed Relevant Electrical Parts • 3rd Drawer Paper Take-Up Sensor PC21 • 3rd Drawer Paper Take-Up Motor M22 • 4th Drawer Paper Take-Up Sensor PC29 • 4th Drawer Paper Take-Up Motor M23 • Vertical Transport Sensor 3 PC17 •...
Page 265 Symptom Step Check Item Result Action • Paper is not Does the paper being used Instruct the user to use the taken up at all. meet product specifications? paper that meets product • Paper is station- specifications. ary before the Is the paper curled, waved or Change the paper.
Page 266 (6) PF-112 Paper Take-Up Misfeed Relevant Electrical Parts • 3rd Drawer Paper Take-Up Sensor PC21 • 3rd Drawer Paper Take-Up Motor M22 • Vertical Transport Sensor 3 PC17 • Vertical Transport Motor M21 • Vertical Transport Sensor 4 PC22 • PF-112 Master Board PWB-A •...
Page 267 Symptom Step Check Item Result Action • Paper is not Does the paper being used Instruct the user to use the taken up at all. meet product specifications? paper that meets product • Paper is station- specifications. ary before the Is the paper curled, waved or Change the paper.
Page 268 (7) AD-11 Vertical Transport/Storage Misfeed Relevant Electrical Parts • Duplex Unit Vertical Transport Sensor PC12 • Exit/Duplex Switching Solenoid SL5 • Duplex Unit Turnover Path Sensor PC13 • Duplex Unit Gate Switching Solenoid SL31 • Duplex Unit Paper Entry Sensor PC14 •...
Page 269 AD-11 Vertical Transport Misfeed Troubleshooting Procedure Symptom Step Check Item Result Action Paper is station- Does SL5 operate properly? Check the drive transmission ary at the copier Using the IC Port Data Check path. exit section. function, set the data of PWB- A (IC4A) BPA5 to “0”.
Page 270 AD-11 Storage Misfeed Troubleshooting Procedure Symptom Step Check Item Result Action The leading edge Is the Paper Guide Mylar dirty Clean or replace the Mylar. of the paper is sta- or deformed? tionary inside the Does PC14 operate properly? Replace PWB-G, PWB-A or Duplex Unit.
Page 271 (8) AD-11 Paper Take-Up Misfeed Relevant Electrical Parts • Duplex Unit Paper Take-Up Sensor PC16 • Duplex Unit Pick-Up Solenoid SL33 • Vertical Transport Sensor 3 PC17 • PF-206/112 Master Board PWB-A • Vertical Transport Motor M21 • Copier Master Board PWB-A •...
Page 272 AD-11 Paper Take-Up Misfeed Troubleshooting Procedure Symptom Step Check Item Result Action Paper is not taken Does SL33 operate properly? Check the Pick-Up Mecha- up at all. Using the IC Port Data Check nism. function, set the data of PWB- Replace PWB-G, PWB-A, A (Dup) (IC1G) PB2 to “0”.
Page 273: Malfunctions
MALFUNCTIONS 4-1. Detection Timings Classified by Malfunction Codes • The codes preceded by an asterisk ( ) are the candidates for isolated malfunctions. • Malfunctions can be reset by the following procedure. Malfunction Resetting Procedure • Open and close the Front Door. The Trouble Reset Switch must be pressed to reset the malfunction of the Fusing and Exposure Lamp Sections.
Page 274 C03## Master Board/Harness Malfunctions • The copier performs a self-diagnostic sequence to determine if the microprocessor out- puts a signal to each of the IC ports on Master Board PWB-A properly. It is intended for detecting the following malfunctions (C03##). •...
Page 275 Code Description Master Board Port C032E Image Erase Lamp 10 IC5A APC7 C033F Image Erase Lamp 9 IC5A APC6 C0330 Image Erase Lamp 8 IC5A APC5 C0331 Image Erase Lamp 7 IC5A APC4 C0332 Image Erase Lamp 6 IC5A APC3 C0333 Image Erase Lamp 5 IC5A APC2...
Page 276 C05## Fusing Malfunctions Code Description Detection Timing Warming-up failure If a given period of time has elapsed during (Fusing Heater Lamp warming-up, the surface temperature of the failure) Upper Fusing Roller does not reach: • 50°C within 30 seconds; • 100°C within 40 seconds after it has reached 50°C;...
Page 277 C06## Optical Malfunctions Code Description Detection Timing • When the Scanner is at a position other than home, Scanner Motor M4 mal- function Scanner Reference Position Sensor PC81 does not go from HIGH to LOW even after the lapse of 20 seconds after the Power Switch has been turned •...
Page 278 Code Description Detection Timing SCEND signal failure The SCEND signal does not go LOW even after the C06F6 (Signal does not go LOW) lapse of 5 seconds after the TRON signal has gone LOW. SCEND signal failure The SCEND signal does not go HIGH even after the C06F7 (Signal does not go HIGH) lapse of 5 seconds after it has gone LOW.
Page 279 Code Description Detection Timing Main Tray upward motion C0990 failure Main Tray downward C0991 motion failure Main Tray downward C0992 motion failure Main Tray upward motion C0993 failure Elevator Motor’s failure to C0994 turn See PF-112 SERVICE MANUAL. C0996 Main Tray ejection failure C0998 Shifter transfer failure C0999...
Page 280 C0F## Sensor Malfunctions Code Description Detection Timing Original Size Detecting In F7 mode: • The Busy signal does not go LOW within approx. Board UN2 malfunction 0.8 sec. after the initial signal has gone LOW, or undefined data is input to the Master CPU. •...
Page 281 Code Description Detection Timing AIDC Sensor Board PWB- In the initial F5 or FF mode, or F5 or FF for every 100 G exposure correction fail- copies made: 1. The Exposure Lamp is turned ON with 58V. 2. A halftone pattern is produced and the PWB-G output is sampled.
Page 282 Code Description Sensor Layout Original Size Detecting <Detection Timing> C0FE1 Sensor failure After having read the output data from PC113 to PC117, UN2 determines that there is a failure. Original Size Detecting C0FE2 Sensor failure <Sensor Layout> Original Size Detecting (Metric Areas) C0FE3 Sensors...
Page 283 Code Description Sensor Layout Original Size Detecting (Metric Areas) C0FF0 • Sensor failure : PC117, : PC113, : PC115 (option), : PC114, : PC116 (option) Original Size Detecting C0FF1 PC115 and PC116 are standard for mixed Sensors failure inch/metric areas. Original Size Detecting •...
Page 284 C0b## Staple Sorter/Sorter Malfunctions Code Description Detection Timing C0b00 Transport drive malfunction See the ST-210/S-207 Service Manual. C0b01 C0b10 Paper Clamp Unit motion See the ST-210/S-207 and ST-101/S-104 Service failure Manuals. C0b11 C0b12 See the ST-210/S-207 Service Manual. C0b13 C0b30 Paper Aligning Mechanism See the ST-210/S-207 and ST-101/S-104 Service drive failure...
Page 285: Troubleshooting Procedures By Malfunction Codes
4-2. Troubleshooting Procedures by Malfunction Codes (1) C0000: Main Drive Motor M9’s Failure to Turn C0001: Main Drive Motor M9 Turning at Abnormal Timing Relevant Electrical Parts • Main Drive Motor M9 • Master Board PWB-A 1149C10TCA T-48...
Page 286 C0000 Step Check Item Result Action Does M9 turn? Replace PWB-A. Set the data of PWB-A (IC4A) APC2 to “0.” Perform the “Controller Board Replace PWB-A. Check.” Is malfunction code • Check the drive coupling. “C031B” displayed? • Replace M9. C0001 Step Check Item...
Page 287: C0010: Pc Drive Motor M1'S Failure To Turn C0011: Pc Drive Motor M1 Turning At Abnormal Timing
(2) C0010: PC Drive Motor M1’s Failure to Turn C0011: PC Drive Motor M1 Turning at Abnormal Timing Relevant Electrical Parts • PC Drive Motor M1 • Master Board PWB-A 1149C11TCA T-50...
Page 288 C0010 Step Check Item Result Action Does M1 turn? Replace PWB-A. Set the data of PWB-A (IC4A) BPA2 to “0.” Perform the “Controller Board Replace PWB-A. Check.” Is malfunction code • Check the drive coupling. “C0321” displayed? • Replace M1. C0011 Step Check Item...
Page 289: C004A: Optical Section Cooling Fan Motor M2'S Failure To Turn C004B: Optical Section Cooling Fan Motor M2 Turning At Abnormal Timing C004C: Cooling Fan Motor M7'S Failure To Turn
(3) C004A: Optical Section Cooling Fan Motor M2’s Failure to Turn C004b: Optical Section Cooling Fan Motor M2 Turning at Abnormal Timing C004C: Cooling Fan Motor M7’s Failure to Turn Relevant Electrical Parts • Optical Section Cooling Fan Motor M2 •...
Page 290 C004A Step Check Item Result Action Does M2 turn? Replace PWB-A. Set the data of PWB-A (IC4A) Replace M2. BPC0 to “0.” C004b Step Check Item Result Action Does M2 turn when the malfunction Replace PWB-A. is reset? Is malfunction code “C004b” dis- Replace PWB-A.
Page 291: C0070: Toner Replenishing Motor M8'S Failure To Turn C0071: Toner Replenishing Motor M8 Turning At Abnormal Timing
(4) C0070: Toner Replenishing Motor M8’s Failure to Turn C0071: Toner Replenishing Motor M8 Turning at Abnormal Timing Relevant Electrical Parts • Toner Replenishing Motor M8 • Master Board PWB-A • Toner Hopper Home Position Sensor PC112 1173C11TAB C0070 Step Check Item Result Action...
Page 292: C0200: Pc Drum / Image Transfer / Separator Charge Corona Malfunction
(5) C0200: PC Drum / Image Transfer / Separator Charge Corona Malfunction Relevant Electrical Parts • High Voltage Unit HV1 • Master Board PWB-A 1173C27TAA Step Check Item Result Action Is the PC Drum / Image Transfer / Install it securely. Separator Charge Corona installed securely? Is the corona housing dirty, the con-...
Page 293: C03##: Master Board/Harness Malfunctions
• Master Board PWB-A • Paper Feeder Option Master Board PWB-A C0300 to C033D Step Action Replace EP3000/EP3010 PWB-A. C0350, C0351, C0352 Step Action Check the connections from PJ22A on PWB-A to PJ2A on PWB-A of the paper feeder option.
Page 294: C0400: Exposure Lamp La1'S Failure To Turn On C0410: Exposure Lamp La1 Turning On At Abnormal Timing
(7) C0400: Exposure Lamp LA1’s Failure to Turn ON C0410: Exposure Lamp LA1 Turning ON at Abnormal Timing Relevant Electrical Parts • Exposure Lamp LA1 • Exposure Lamp Regulator PU2 • Exposure Thermal Fuse TF1 • AE Sensor Board PWB-H •...
Page 295 Step Check Item Result Action Does the voltage across PWB-A Go to step 2 PJ36A-4 and GND become DC0V (L) when the Start key is pressed? Perform the “Controller Board Replace PWB-A. Check”. Is malfunction code “C0312”, “C0313” or “C033C” dis- played? Disconnect CN7.
Page 296: C0510: Abnormally Low Fusing Temperature
(8) C0500: Warming-up Failure C0510: Abnormally Low Fusing Temperature C0520: Abnormally High Fusing Temperature Relevant Electrical Parts • Fusing Heater Lamp H1 • Fusing Heater Lamp SSR SSR1 • Fusing Thermoswitch TS1 • Master Board PWB-A • Fusing Thermistor 1 TH1 •...
Page 297 C0500, C0510 Step Check Item Result Action Does H1 light up when the Power Go to step 5 Switch is turned ON? Is TH1 installed properly? Reinstall TH1. Is TH1 dirty? Clean or replace TH1. Measure the resistance of TH1. Is it Replace TH1.
Page 298: C06Fx: Signal Failure
(9) C0600: Scanner Motor M4 Malfunction C06FX: Signal Failure C0610: Lens Motor M5 Malfunction C0620: Mirror Motor M6 Malfunction Relevant Electrical Parts • Scanner Motor M4 • Mirror Reference Position Sensor PC86 • Lens Motor M5 • Lens Reference Position Sensor PC90 •...
Page 299 C0600 Step Check Item Result Action Are all connectors on PWB-F Plug them in securely. plugged in securely? When PC81 is blocked, does the Check the Scanner Drive Cable for voltage across PWB-A PJ39-1 and tension and overload. GND change from DC5V to DC0V? Or, replace PWB-A.
Page 300 (10) C0910: 2nd Drawer Upward Motion Failure C0914: 2nd Drawer Paper Lift-Up Motor M14’s Failure to Turn C0920: 1st Drawer Upward Motion Failure C0924: 1st Drawer Paper Lift-Up Motor M13’s Failure to Turn Relevant Electrical Parts • 1st Drawer Lift-Up Sensor PC65 •...
Page 301 C0910 Step Check Item Result Action Does PC66 operate properly? Replace PWB-A. Using the IC Port Data Check func- Check the operation of the Paper tion, make an input port check on Take-Up Roll. If it is okay, replace PWB-A (IC3A) APB2. PC66.
Page 302: C0950: 4Th Drawer Upward Motion Failure
(11) C0900: 3rd Drawer Upward Motion Failure C0904: 3rd Drawer Paper Lift-Up Motor M24’s Failure to Turn C0950: 4th Drawer Upward Motion Failure C0954: 4th Drawer Paper Lift-Up Motor M25’s Failure to Turn Relevant Electrical Parts • 3rd Drawer Paper Lift-Up Sensor PC19 •...
Page 303 C0950 Step Check Item Result Action Does PC19 operate properly? Replace PWB-A (PF-206). Using the IC Port Data Check func- Check the operation of the Paper tion, make an input port check on Take-Up Roll. If it is okay, replace PWB-A (200) (IC1A) PG3.
Page 304: C0991: Main Tray Downward Motion Failure
(12) C0990: Main Tray Upward Motion Failure C0991: Main Tray Downward Motion Failure C0992: Main Tray Downward Motion Failure C0993: Main Tray Upward Motion Failure C0994: Main Tray Elevator Motor M26’s Failure to Turn Relevant Electrical Parts • Main Tray Lower Position Sensor PC2 •...
Page 305 C0990, C0991 Step Check Item Result Action Replace PWB-A (PF-112). Does PC19 operate properly? Using the IC Port Data Check func- Check the operation of the Paper tion, make an input port check on Take-Up Roll. If it is okay, replace PWB-A (400) (IC1A) PG3.
Page 306: C0999: Shifter Return Failure
(13) C0998: Shifter Transfer Failure C0999: Shifter Return Failure C099A: Shifter Return Failure C099b: Shifter Transfer Failure C099C: Paper Shift Motor M27’s Failure to Turn Relevant Electrical Parts • Shifter Home Position Sensor PC3 • Paper Shift Motor M27 • Shifter Return Position Sensor PC4 •...
Page 307 C0998, C0999 Step Check Item Result Action Does PC4 operate properly? Replace PWB-A (PF-112). Using the IC Port Data Check func- Replace PC4, PWB-H or flat cable. tion, make an input port check on PWB-A (400) (IC2A) PD1. C099A, C099b Step Check Item Result...
Page 308: C099E: Shift Gate Position Detecting Failure C099F: Shift Gate Position Detecting Failure C0996: 3Rd Drawer Lock Release Failure C0F79: Paper Empty Sensor Failure
(14) C099E: Shift Gate Position Detecting Failure C099F: Shift Gate Position Detecting Failure C0996: 3rd Drawer Lock Release Failure C0F79: Paper Empty Sensor Failure Relevant Electrical Parts • Shift Tray Paper Empty Sensor PC1 • Shift Gate Position Detecting Sensor PC34 •...
Page 309 C099E, C099F Step Check Item Result Action Does PC34 operate properly? Replace PWB-A (PF-112). Using the IC Port Data Check func- Replace PC34, PWB-H or flat tion, make an input port check on cable. PWB-A (400) (IC1A) PC1. C0996 Step Check Item Result Action...
Page 310: C0D20: Duplex Unit Gate Unit Home Position Detection Failure
(15) C0d00: Duplex Unit Front/Rear Edge Guide Plates Home Position Detection Failure C0d20: Duplex Unit Gate Unit Home Position Detection Failure C0d50: Duplex Unit Drive Motor M31’s Failure to Turn C0d51: Duplex Unit Drive Motor M31 Turning at Abnormal Timing Relevant Electrical Parts •...
Page 311 C0d00 Step Check Item Result Action Does M33 turn when the Front/Rear Check for overload. Edge Guide Plates are moved to Replace M33 or PWB-G. other than the home position and the Duplex Unit is slid in? Does PC9 operate properly? Replace PWB-G.
Page 312: C0F02: Original Size Detecting Board Un2 Failure C0Fe1 To C0Fff: Original Size Detecting Sensor Failure
(16) C0F02: Original Size Detecting Board UN2 Failure C0FE1 to C0FFF: Original Size Detecting Sensor Failure Relevant Electrical Parts • Original Size Detecting Sensor FD2 PC113 • Original Size Detecting Board UN2 • Original Size Detecting Sensor DC1 PC114 • Master Board PWB-A •...
Page 313 C0F02 Step Check Item Result Action Are PJ17 on UN2 and PJ4A on Plug them in securely. PWB-A plugged in securely? Does the voltage across PJ4A-6 on Replace PWB-A. PWB-A and GND vary between Replace UN2. DC0V and DC5V? C0FE1 to C0FFF Step Check Item Result...
Page 314: C0F10: Ae Sensor Board Pwb-H Failure
(17) C0F10: AE Sensor Board PWB-H Failure Relevant Electrical Parts • AE Sensor Board PWB-H • Master Board PWB-A 1149C26TAA Step Check Item Result Action Is the voltage across PWB-A PJ5A- Replace PWB-H. 3 and GND less than DC0.18V Replace PWB-A. when the Scanner is at the home position, the Exposure Lamp is OFF, and the Original Cover is low-...
Page 315: C0F23: Aidc Sensor Board Pwb-G Exposure Correction Failure
(18) C0F20: AIDC Sensor Board PWB-G Variation Correction Failure C0F22: AIDC Sensor Board PWB-G Grid Voltage Correction Failure C0F23: AIDC Sensor Board PWB-G Exposure Correction Failure Relevant Electrical Parts • AIDC Sensor Board PWB-G • Master Board PWB-A 1149C27TAA Step Check Item Result Action...
Page 316: C0F30: Atdc Sensor Un3 Failure C0F31: Atdc Sensor Un3 Failure
(19) C0F30: ATDC Sensor UN3 Failure C0F31: ATDC Sensor UN3 Failure Relevant Electrical Parts • ATDC Sensor UN3 • Master Board PWB-A 1149C28TAA Step Check Item Result Action Is the malfunction code displayed Go to step 3 “C0F31”? Is the value for “ATDC Ref. Value” Enter the value given on the Adjust of “Level History”...
Page 317: Power Malfunctions
4-3. Power Malfunctions (1) Main Relay Does Not Turn ON Relevant Electrical Parts • Power Switch S1 • Master Board PWB-A • Main Relay RY1 • Power Supply Board PWB-C • Power Supply Unit PU1 • Noise Filter Board PWB-D •...
Page 318 European Areas 1173C24TAB Step Check Item Result Action Is the source voltage applied to the Replace PWB-D. circuit across PJ1-1 and -2 on Check the wiring of S1. PU1? Is the voltage across PJ2-2 and 3 Check the fuse on PU1. If it is nor- on PU1 and GND DC24V? mal, replace PU1.
Page 319: Main Relay Turns On But The Control Panel Gives No Display
(2) Main Relay Turns ON But the Control Panel Gives No Display Relevant Electrical Parts • Power Supply Unit PU1 • Master Board PWB-A • Control Panel UN1 • Power Supply Board PWB-C 1173C25TAC Step Check Item Result Action Is the voltage across PJ2C-6 on Check the wiring between PWB-C PWB-C and GND DC24V? and UN1.
Page 320: Miscellaneous
4-4. Miscellaneous • The message “Stabilizing Image Controller not run.” appears on the Touch panel Condition Detection Timing • When memory clear is run. T/C is less than 4% when an F5 operation is • “PC Drum” of “Port/Option” counter is run (initial adjustment).
Page 321: Image Failure
IMAGE FAILURE 5-1. Image Failure Troubleshooting Image failures have many possible causes. For troubleshooting, it is necessary to deter- mine whether a failure is attributable to a basic cause or any other cause. In this chapter, troubleshooting is divided into “initial checks” and “troubleshooting proce- dures classified by image failure”.
Page 322 6. Adjustment items (registration, focus, AE level, etc.) • Among the adjustment items given in DIS/REASSEMBLY, ADJUSTMENT, is there any adjustment that may remedy the image failure? 7. Controller Board Check • Is a malfunction code displayed when “Controller Board Check” in the Tech. Rep. mode is run? T-85...
Page 323: Troubleshooting Procedures Classified By Image Failures
5-3. Troubleshooting Procedures Classified by Image Failures <Image Failure Samples> 1. Blank Copy 2. Black Copy 3. Low image density 4. Foggy background 5. Black streaks or bands 6. Black spots Feeding Direction 7. Blank streaks or bands 8. Void areas 9.
Page 324 1. Blank Copy Cause Step Check Item Result Action Charging failure Is the PC Drum Charge Install correctly. Corona installed correctly? Are the PC Drum Charge Check and replace if neces- Corona wire and grid mesh sary. normal? Is the wiring between High YES Replace HV1.
Page 325 3. Low Image Density Cause Step Check Item Result Action PC Drum life Does the PC Drum have Replace the PC Drum. enough service life? Do the fan motors turn prop- Troubleshoot the fan motors. erly? (Ozone deterioration, temperature rise) PC Drum ground- Is the PC Drum properly Clean or replace the PC Drum...
Page 326 4. Foggy background Cause Step Check Item Result Action Cleaning failure Is the Cleaning Blade dirty with Change the Cleaning Blade. foreign matter, paper dust, etc. or is it scratched? Optical failure Is the mirror or lens dirty? YES Clean the mirror or lens. PC Drum failure Is the PC Drum dirty with for- Clean or replace the PC Drum.
Page 327 5. Black Streaks or Bands Cause Step Check Item Result Action Uneven charging Are the PC Drum Charge Clean or replace the PC Drum Corona wire and grid mesh Charge Corona. dirty? Check the operation of the toner charging mechanism. Cleaning failure Is the Cleaning Blade dirty with Replace the Cleaning Blade.
Page 328 7. Blank Streaks or Bands Cause Step Check Item Result Action Plugged Db Is the Db plugged with foreign Remove foreign matter. If the matter, caked toner, etc.? problem persists, replace the developer. Drum charge fail- Are the PC Drum Charge Clean or replace the PC Drum Corona wire and grid mesh Charge Corona.
Page 329 8. Void Areas Cause Step Check Item Result Action Image transfer fail- Is the Image Transfer Corona Reinstall. installed correctly? Is the Image Transfer Corona Clean or replace the Image wire dirty? Transfer Corona wire. Damp copy paper Is the image improved by load- Change the copy paper and ing new paper? instruct the user in how to...
