O
VERVIEW
1 –
SmartNA™ 10G Network Access (SmartNA-X) provides a flexible and customizable Test Access Point (TAP)
solution. This chapter covers the following major topics:
• SmartNA-X features, page 3
• Hardware overview, page 3
• Managing SmartNA-X, page 5

SmartNA-X features

SmartNA-X 10G Network Access is a fully configurable filtering 10G TAP device that provides the following
advanced TAP features:
• Fail-safe ports
• Traffic replication and aggregation capabilities
• Flexible port maps
• Advanced packet filtering capabilities, including ability to filter 10G traffic to continue using 1G tools
• Ability to aggregate 1G links to a 10G port
• SSL secured management interfaces
• Easy to use web UI with support for click-n-drag port mappings.
• SNMP remote status monitoring and alert notifications
• Local or external authentication and authorization via RADIUS and TACACS+
• Hot-swappable TAP modules
• Optional dual independent PSUs for redundancy protection against single point power failure
• Three user access levels: Administrator, Operator and Auditor

Hardware overview

The SmartNA-X chassis
hot-swappable, fully configurable and available in various configurations of copper, single mode fiber, multi-mode
fiber, and SFP/SFP+ ports. Slot 1 supports 10 Gbit/s TAP modules (colored red), slots 2, 3 and 4 support 1 Gbit/
s TAP modules (colored blue). Four ports on each module are used to TAP live traffic and direct it to output ports
(Figure 1-1 and Figure 1-2) supports four independently operating TAP modules that are
DRAFT
1
C
HAPTER
3
