ONFIGURING PORTS ONFIGURING PORT TRAFFIC THRESHOLDS
The following example session enables TAP mode on ports on ports 2A and 2B:
CONTROLLER>select slot 2
SLOT1>select slot 2
SLOT2>set port a tap on
SLOT2>set port b tap on
SLOT2>show port a
speed
duplex
mdi
mastering
tap
autolock
lock
usage
port type
PORT DOWN
traffic threshold low : 0
traffic threshold high: 100
SLOT2>show port b
speed
duplex
mdi
mastering
tap
autolock
lock
usage
port type
PORT DOWN
traffic threshold low : 0
traffic threshold high: 100
SLOT2>

Configuring port traffic thresholds

You can configure upper and lower traffic thresholds for a port as a percentage of the overall available channel
capacity. If the amount of data on the channel reaches either of these thresholds, an SNMP traffic trap is sent to
SNMP clients configured to receive these type of traps. See [Configuring SNMP clients]. A clear trap will also be
sent when traffic returns to normal levels [how many % above/below thresholds].
By default, traffic thresholds are set to 75% and 50%. In most cases, these settings will provide adequate
forewarning of ports being overloaded or under utilized, conditions which may indicate network or port issues
requiring administrator attention.
Using the web UI to port traffic thresholds
Select the port you want to configure.
1.
Select the Health tab.
2.
: set auto
: set auto
: set auto
: set preferslave
: on
: off
: on
: undefined
: Registered Jack 45 (RJ45)
: set auto
: set auto
: set auto
: set preferslave
: on
: off
: off
: undefined
: Registered Jack 45 (RJ45)
