Network Critical SmartNA-X User Manual page 151

C L I R
OMMAND INE NTERFACE EFERENCE
Examples • Set up IPv4/IPv6 filter for TCP/UDP traffic from MAC address 01:23:45:67:89:ab to MAC addresses
01:23:45:67:89:ab or 01:23:45:67:89:ac:
CONTROLLER>set filter tcp6_traffic ipv6 protocol tcp_udp mac src
01:23:45:67:89:ab,01:23:45:67:89:ac mac dest 01:23:45:67:89:ab,01:23:45:67:89:ac
CONTROLLER>show filters
Use commit command to configure the switch with these.
filters
tcp6_traffic
CONTROLLER>commit
Committing maps and filters
|
[ dscp-value] (Optional) Filters on the specified value matching the DSCP
dscp
number. Use commas if specifying multiple DSCP values.
[
port src
number. For prt-value, the following formats are recognized:
• 10 – A single port
• 10-20 – A range (inclusive)
• 10,15 – Multiple ports (multiple ports may each use a range). Use commas (no
spaces) to separate ports.
[
port dest
destination port number.
[
port either
source port number or the destination port number.
packetType : ipv6
protocol : 6,17
ipv6
source : 2001:db8:85a3::8a2e:370:7334
destination : 2000:abcd::77:88-99
S NA™ 10G N
MART
prt-value] (Optional) Filters on the specified value matching the source port
prt-value] (Optional) Filters on the specified value matching the
prt-value] (Optional) Filters on the specified value matching either the
DRAFT
A (S NA-X)
ETWORK CCESS MART
146
