Port tab

The Port configuration tab
shown in
Figure B-9 The Port configuration tab
Table B-14 Port configuration tab options
Option
Description
Usage
Type
Speed
| P
ORT TAB
(Figure B-9) is available after clicking on a port. It provides access to the port settings
Table B-14.
Description
Enter a description for the port's intended purpose to be entered.
Declares the port's intended usage:
Tool – Port is connected to a network tool, such as a monitoring computer or data analysis equipment
Network – Port is connected to a live network
Unknown – Usage is not known/open
This setting is optional (the port will operate as normal whatever setting is selected).
Show the port type, either SFP (1G port), SFP+ (10G port) or RJ (1G port).
Sets the link speed, limiting the port to the selected value (even if the link partner doesn't support it). Auto
(negotiated speed) can be used for all ports which support this setting but may introduce a fail to safe
delay operating in 'TAP' mode. See the
40 for instructions.
Available for copper ports only.
S NA™ 10G N
MART
"Configuring port failsafe and LFP (TAP mode)" section on page
