C L I R
OMMAND INE NTERFACE EFERENCE
• Set up IPv4 filter for TCP and UDP packets on ports 80 (HTTP), 8080 (HTTP alternative), and 443
(HTTPS) from source addresses 10.10.0.* to destination addresses 192.168.0.*:
CONTROLLER>set filter html_traffic ipv4 protocol tcp_udp port src 80,8080,443 address src
10.10.0.* address dest 192.168.0.*
CONTROLLER>show filters
html_traffic
CONTROLLER>commit
Committing maps and filters
• Set up ARP filter for TCP/UDP traffic from MAC address 01:23:45:67:89:ab to MAC addresses
01:23:45:67:89:ab or 01:23:45:67:89:ac:
CONTROLLER>set filter tcp6_traffic ipv6 protocol tcp_udp mac src
01:23:45:67:89:ab,01:23:45:67:89:ac mac dest 01:23:45:67:89:ab,01:23:45:67:89:ac
CONTROLLER>show filters
Use commit command to configure the switch with these.
filters
tcp6_traffic
CONTROLLER>commit
Committing maps and filters
|
packetType : ipv4
protocol : 6,17
port
source : 80,8080,443
ipv4
source : 10.10.0.*
destination : 192.168.0.*
packetType : ipv6
protocol : 6,17
ipv6
source : 2001:db8:85a3::8a2e:370:7334
destination : 2000:abcd::77:88-99
