ET PORT TAP

Use the set port tap command to configure the specified ports as TAP ports of the currently selected TAP module.
TAP ports connect to the live network and as such must provide link-up status at all times. In the event of a power
failure or a module being pulled, a relay switch is instantly closed to maintain the network connection when TAP
is on. TAP off can be used when connecting to network tools, to prevent data being captured when a module is
pulled or when a general port failure has occurred.
Command form set port port-id tap {
port-id
|
on off
Example Enable TAP mode for port 4C:
CONTROLLER>select slot 4
SLOT4>set port C tap on
SLOT4>show port C
speed
duplex
mdi
mastering
tap
autolock
lock
usage
port type
PORT DOWN
traffic threshold low : 10
traffic threshold high: 100
|
| }
on off
Specifies the port to set. Front ports are labelled A to D, left to right, and rear ports
are labelled A and B. Only one port can be set at a time.
Sets the TAP mode to on or off. Off is the default setting for ports.
: set 1G
: set auto actual full
: set mdi-x
: set preferslave
: on
: off
: off
: undefined
: Registered Jack 45 (RJ45)
