Select the TAP checkbox (if it is not already selected), as shown in
3.
selected in the pair (AB and CD).
Figure 6-2 Port configuration tab (TAP checkbox shown)
Click Review/apply and review the changes you have made, and then click Apply to implement your changes.
4.
Using the CLI to enable TAP mode
Log in to the CLI as Administrator.
1.
Select the TAP module you want to configure.
2.
CONTROLLER>select slot 4
Enter the following command to enable TAP mode on port A (port B is automatically enabled as a result):
3.
SLOT4>set port A tap on
SLOT4>show port A
speed
duplex
mdi
mastering
tap
autolock
lock
usage
port type
PORT DOWN
traffic threshold low : 10
traffic threshold high: 100

Testing failsafe

You can test failsafe is enabled correctly as follows:
Set up failsafe on a port pair, as described in the
1.
page
LFP (TAP
: set 1G
: set full
: set mdi-x
: set preferslave
: on
: off
: off
: undefined
: Registered Jack 45 (RJ45)
40.
S NA™ 10G N
MART
)
MODE
Figure
TAP OPTION
"Configuring port failsafe and LFP (TAP mode)" section on
