Enabling Transaction Logging - Network Critical SmartNA-X User Manual

A S NA-X | E
DMINISTERING MART

Enabling transaction logging

For auditing purposes, all SmartNA-X transactions can be logged to a RADIUS or TACACS+ accounting server.
Local logging is not supported by the system. This section explains how to enable accounting servers using the web
UI and CLI.
Using the web UI to configure accounting servers
Log in to the web UI.
1.
Click on the main chassis area to access system management settings.
2.
Select the Security tab.
3.
Add or edit
4.
For RADIUS servers, specify the following configuration options:
• Server address: Specifies the network address of the accounting server.
• Server port: Specifies the communication port, usually 1813 for accounting servers.
• Shared secret: Specify the password/shared-secret required to access the accounting server. Passwords are
case-sensitive.
For TACACS+ servers, specify the following configuration option:
• Server address: Specify the network address of the accounting server.
To edit an existing server, click the
Click Add server to finish setting up the server.
5.
Add any backup servers employed on your network. You can use the
6.
contact order.
Click Review/apply, review the changes you have made, and then click Apply to implement the new settings.
7.
Using the CLI to add accounting servers
Enable the protocol used by the accounting server (RADIUS and TACACS+ protocols are supported):
1.
CONTROLLER>set accounting {radius | tacacs}
Add a master authentication server and any backups employed by your network.
2.
• To add a RADIUS accounting server:
CONTROLLER>create radius accserver <IP-address> <port-num> <password>
• To add a TACACS+ accounting server:
CONTROLLER>create tacacs accserver <IP-address> <password>
Exit the CLI in order to apply your changes:
3.
CONTROLLER>exit
NABLING TRANSACTION LOGGING
a RADIUS or TACACS+ accounting server.
S NA™ 10G N
MART
button.
DRAFT
A (S
ETWORK CCESS MART
button to drag servers into desired
NA-X)
29
