W U -I R
EB SER NTERFACE EFERENCE
numbers that may be requested by Network Critical Support if support is required.Refer to
details of the information that is available in the Health tab.
Figure B-6 The Health tab
Table B-12 Health tab options
Status
Fan 1, Fan 2
Firmware build
Firmware revision
Hardware revision
Model number
PSU 1, PSU 2
Serial number
System status
System temperature
System uptime
| H
EALTH TAB
Description
Shows the state of each fan, either up (working) or down (not working).
Shows the firmware build date.
Shows the firmware revision. You may be asked to provide this information when contacting Network
Critical Support.
Shows the hardware version. You may be asked to provide this information when contacting Network
Critical Support.
Shows the SmartNA-X model number. You may be asked to provide this information when contacting
Network Critical Support.
Shows the state of the power supply units, either up (connected) or down (not connected). For power
outage redundancy, connect to independent power supplies.
Show the serial number. You may be asked to provide this information when contacting Network Critical
Support.
Shows the overall health of the system. Under normal circumstances, the system status will always be
'OK'. If an internal error is detected, the system status will change to 'Contact Network Critical'. If
configured, an SNMP system health (SH) notification will also be sent should this condition occur. See
the "SNMP tab" section on page 195
Shows the temperature of the SmartNA-X chassis. If the temperature rises above a set threshold, an
SNMP notification will be sent to your configured SMNP managers.
Shows the length of time in days, hours, minutes and seconds since the last reboot.
S NA™ 10G N
MART
for instructions on enabling the SH notification.
DRAFT
A (S NA-X)
ETWORK CCESS MART
Table B-12 for more
