Network Critical SmartNA-X User Manual page 155

C L I R
OMMAND INE NTERFACE EFERENCE
S
ET FILTER MPLS LABEL
Use the set filter mpls label command to create a filter for MPLS (Multiprotocol Label Switching) packets with an
ethertype of 0x8847 or 0x8848 (the system does not process MPLS encapsulated in IP). The filter can be further
refined by specifying an MPLS label. Packets matching an applied filter will either be passed or dropped,
depending the criteria specified in the set map command.
Command form set filter name-string mpls label value,...
name-string
value
Example Set up a filter for MPLS label 100:
CONTROLLER>set filter mpls_traffic mpls label 10
|
Specifies the filter name. It may contain spaces, but if it does, it must be contained in
quotes "..."; the name itself may not contain the quotes character.
Filter traffic by MPLS label. Where the MPLS header for a packet contains multiple
labels, this will test the top label in the stack. The following formats are recognized:
• 100 – A single label
• 100-110 – A range (inclusive)
• 100,150 – Multiple labels (may also use ranges). Use commas (no spaces) to
separate labels.
S NA™ 10G N
MART
DRAFT
A (S NA-X)
ETWORK CCESS MART
150
