O | M S NA-X
VERVIEW ANAGING MART
To manage module and port settings, you must select the chassis slot that the module is installed in. Slot are
numbered 1–4, left to right; the rear slot is slot 0. For example, to manage a module in the third slot, enter the
following command:
CONTROLLER>select slot 3
SLOT 3>
Command overview
The CLI supports the following set of commands:
• Help – displays help information for the specified set of commands. For example, help set displays help for set
commands, help show displays help for show commands, and help auth displays information on authorization
commands.
• Select – selects a slot or the SmartNA-X system management options, making it the current home location. For
example, select slot 1 selects the first slot, select controller selects SmartNA-X system management options.
Other commands may implicitly use the current location, for example in deciding which port a show port
command refers to.
• Set – writes system parameters. Set commands are limited to SmartNA-X Administrators and have no effect
when entered by users with Operator/user or Audit access.
• Show – reads system parameters and displays them on the screen.
• Create settings – saves the current system parameters to permanent memory.
• Restore – restores a previously saved set of parameters, discarding any unsaved changes in the process.
• Delete – deletes a previously saved set of parameters.
• Clear – clears counters or maps (depending on the clear command entered).
• Commit – commits changes to maps and filters.
• Reboot – reboots TAP modules and system motherboard.
• Exit/Quit – exits the CLI and implements any network changes made to the system.
Commands may be entered in UPPERCASE, lowercase, or a CoMbinAtioN of both.
Logging out
To logout of the CLI, enter exit or quit:
CONTROLLER>exit
Logging out allows other users to access the CLI and web UI (the management interfaces permit single user access
only), and applies changes to network configuration.
