Network Critical SmartNA-X User Manual page 23

S S NA-X | L
ETTING UP MART OGGING IN TO
• a terminal client supporting SSH (Secure Shell)
Start your terminal client and enter the following command (where admin is the username and
1.
192.168.254.100 is the default IP address):
user@example.com ~# ssh admin@192.168.254.100
Enter "yes" to accept the host connection if this is the first time you have connected from this host.
2.
The authenticity of host '192.168.254.100' can't be established.
RSA key fingerprint is 9a:30:7b:95:ec:b4:fe:53:e1:a4:42:69:4f:15:5c:1a.
Are you sure you want to continue connecting (yes/no)? yes
Warning: Permanently added '192.168.254.100' (RSA) to the list of known hosts.
Enter your SmartNA-X admin password to login:
3.
admin@192.168.254.100's password:*****
CONTROLLER>
For help in the CLI, you can use the help command. For example, to see a list of authentication and
4.
authorization commands that are available, enter help auth:
CONTROLLER>help auth
The following are associated with authentication and authorization :
set authentication {Local, RADIUS, TACACS} : defines type of authentication
create radius authserver <Address> <Port> <shared secret> : add RADIUS
authentication server. <Port> should normally be 1812 for authentication
servers
delete radius authserver <Address> : remove RADIUS authentication server
create radius accserver <Address> <Port> <shared secret> : add RADIUS
accounting server. <Port> should normally be 1813 for accounting servers
delete radius accserver <Address> : remove a RADIUS accounting server
create tacacs authserver <Address> <shared secret> : add TACACS+
authentication server
delete tacacs authserver <Address> : remove TACACS+ authentication server
create tacacs accserver <Address>
add TACACS+ accounting server (with logging implicitly enabled)
delete tacacs accserver <Address> : remove an accounting server
show radius : show radius servers
show tacacs : shows TACACS+ servers
set log <text> : creates a log entry with <text> if accounting is enabled.
user@example.com ~#
Logging in to the CLI locally
To log in to SmartNA-X as Administrator locally (without a network connection), you'll need:
• direct connection from a PC to the Console/Serial port using a DE-9 female to 8P8C (RJ45) serial management
cable (supplied)
• a SmartNA-X admin username and password (see
• a terminal emulator client
Connect the DE-9 female to 8P8C serial management cable from PC to Console/Serial port
1.
S NA-X
MART
DRAFT
S NA™ 10G N
MART
<shared secret>:
Table 3-1 for the defaults)
A (S NA-X)
ETWORK CCESS MART
(Figure 3-6).
18
