C L I R
OMMAND INE NTERFACE EFERENCE
S MDI

ET PORT

Use the set port mdi command to specify the crossover mode of the port, either MDI (normal) or MDI-X
(crossover). To connect two ports of the same configuration (MDI to MDI or MDI-X to MDI-X), an Ethernet
crossover cable is needed to cross over the transmit and receive signals in the cable, so that they are matched at the
connector level. Otherwise, you can select Auto and let the ports themselves detect the required cable connection
type and configure the connection appropriately. For auto-MDI/MDI-X to operate correctly, the data rate on the
interface and duplex setting must be set to Auto.
Command form set port port-id mdi {
port-id
Auto
Examples • Set port 4C to MDI-X:
CONTROLLER>select slot 4
SLOT4>set port C mdi mdi-x
SLOT4>show port C
speed
duplex
mdi
mastering
tap
autolock
lock
usage
port type
PORT DOWN
traffic threshold low : 10
traffic threshold high: 100
• Set port 4D to MDI:
CONTROLLER>select slot 4
SLOT4>set port D mdi mdi
SLOT4>show port D
speed
duplex
mdi
mastering
tap
autolock
lock
usage
port type
PORT DOWN
traffic threshold low : 0
traffic threshold high: 100
|
| |
auto mdi mdi-x
Specifies the port to set. Front ports are labelled A to D, left to right, and rear ports
are labelled A and B. Only one port can be set at a time.
| | Sets the MDI/MDI-X transmission mode. Default setting is Auto.
MDI MDI-X
: set 1G
: set auto actual full
: set mdi-x
: set preferslave
: off
: off
: off
: undefined
: Registered Jack 45 (RJ45)
: set auto
: set auto actual full
: set mdi
: set preferslave
: off
: off
: off
: undefined
: Registered Jack 45 (RJ45)
