C L I R
OMMAND INE NTERFACE EFERENCE
S
ET FILTER ANY
Use the set filter any command to create a filter for matching VLAN, or MAC source, or MAC destination (of
either source and destination) header information for any EtherType. Packets matching an applied filter will either
be passed or dropped, depending the criteria specified in the set map command.
Command form set filter name-string any [any-conditions ...]
name-string
any-conditions
|
Specifies the filter name. It may contain spaces, but if it does, it must be contained in
quotes "..."; the name itself may not contain the quotes character.
(Optional) Provides additional filtering conditions for the specified protocol. All
conditions must be satisfied for the filter to match. The following additional filtering
conditions may be specified:
[ vl-value] (Optional) Filters on the specified value matching the VLAN number.
vlan
For vl-value, the following formats are recognized:
• 100 – A single tag
• 100–110 – A range (inclusive)
• 0/1 – A value/mask pair (here: all even tags)
• 100,150 – Multiple tags. Use commas (no spaces) to separate VLANs.
The following caveats should be noted when filtering by VLAN:
• When a filter is set to permit VID 1, untagged packets will still be forwarded.
• Tagged packets with a VID of 1 will be forwarded untagged.
• Tagged packets with a VID of 0 will be dropped by SmartNA-X.
[ mac-value] (Optional) Filters on the specified value matching the source
mac src
MAC address. For mac-value, the following formats are recognized:
• 01:23:45:67:89:ab – A single address
• 01:23:45:67:89:ab,01:23:45:67:89:ac – Multiple addresses. Use commas (no
spaces) to separate addresses.
[ mac-value] (Optional) Filters on the specified value matching the
mac dest
destination MAC address.
[ mac-value] (Optional) Filters on the specified value matching either the
mac either
source or destination MAC address.
