S S NA-X | L
ETTING UP MART OGGING IN TO
Set up the terminal emulator program as 9600 baud, 8 data bits, No parity, 1 stop bit (8N1).
2.
Start a session to SmartNA-X and login with your Admin username and password:
3.
Username : admin
Password : ******
Login over serial connection
Command Line Parser
Built on Sep 25 2012 at 15:29:17 from svn revision 263M
Running at Authorisation level 3
User admin logged in from serial-connection
CONTROLLER>
Use regular SmartNA-X CLI commands to configure settings. For example, to configure the following network
4.
settings:
IP: 192.168.0.122
subnet mask: 255.255.255.0
gateway: 192.168.0.254
enter the following commands:
CONTROLLER>set ipv4 static 192.168.0.122 255.255.255.0 gateway 192.168.0.254
Network settings will take effect when you exit CLI.
exit to enable new network settings
CONTROLLER>exit
Exiting CLI
exit to enable new network settings
Applying new IPv4 network settings
Addressing Mode : static
Address: 192.168.0.122
Netmask: 255.255.255.0
Gateway: 192.168.0.254
Connection to 192.168.0.122 closed.
admin@example.com:~$
NOTE: If the Console cable is disconnected before the session is terminated, the session over the Console/Serial
port will stay active and prevent any login to the Management/Network port via web UI or CLI. If this happens,
re-connect to the system using the Console/Serial port and shut down the session properly by logging out.
The system allows only one user to be logged in at a time and will actively prevent another user from gaining access
to the system when attempting to connect via the Management/Network port. However, if a user attempts to log
in via the Console/Serial port, this will (by design) disconnect any other UI session that is currently active.
In the event that someone logs in on the Console/Serial port while another UI is already performing some time-
consuming operation, such as applying a complicated mapping and filtering configuration, what happens to that
pending operation will depend on how far it has progressed. In particular, if it has already passed security checks
and started reconfiguring the system, it will attempt to complete its changes even though the original UI session
has expired.
In this case, the administrator who has logged in on the Console/Serial port may see unusual or inconsistent
settings via their CLI until the long-running operation completes, and we recommend against attempting to
change any settings via the Console CLI during this period. If in doubt, we recommend that the administrator
