Pedal Box - Factory Five Racing Mk3 Roadster Assembly Manual

2. Cut-off the marked area with a hack saw. This is necessary for steering shaft clearance.

1994-1995 Pedal Box

1. Cut the corner off the outside top of the pedal box.
Top outside of pedal box.
2. Remove the cruise control switch located under the plastic clutch quadrant on the right side of the
pedal box.
3. Drill out the four spot welds on the front face of the pedalbox.
4. Cut off the corner of clutch quadrant stop shown in the picture below for accelerator pedal clearance.
Cut line
Locations of spot welds and area to remove on clutch quadrant stop.
31
