Pedal Box - Factory Five Racing Mk4 Roadster Assembly Manual

Pedal Box

½", / " sockets, ⅜",
9
16
Hammer, Vise or 2 pieces of 2 x 4, Razor knife or file or grinder, snap ring pliers.
Pedal Components, pedal box hardware.
This pedal box is set-up to use either a hydraulic clutch or a cable clutch. The parts and
instructions required for a cable clutch installation are included in this kit.
Unpack the pedal box assembly. Now is a good time to paint all of the bare steel brackets.
/ ", ½", / " wrenches, Drill,
11 9
32 16
