Rear Quick Jack Bumpers; Side Body Mounts - Factory Five Racing Mk3 Roadster Assembly Manual

ATTENTION: If you ordered the optional chrome bumper assembly, follow the instructions for these
under the optional accessories section near the end of this manual. The quick jack bolts can be
installed from the outside of the car so the gas tank does not have to be dropped.
TOOLS: / " and ⅝"combination wrenches, ⅝" socket,
9
16
PARTS: Quick jack bumper components (FFR# 10533)
Frame
1. Lower the gas tank using a jack in the middle of the tank to hold it. You'll need a
hex key. This is necessary in order to insert the bolts for the quick jacks into their holes.
2. Mount the rear quick jacks using the 3.75" and 1.75" stainless spacers with 4 washers on each long
bolt. Use a ⅝" wrench and ⅝" socket.
3. Raise and bolt the gas tank back into place.
4. Tighten the gas tank strap bolts with a
Slide the nose on first with the body up in the air

Rear Quick Jack Bumpers

Washers
Bolt
3.75" spacer
Body
/ " hex key and
5
16

Side Body Mounts

www.factoryfive.com
/ " hex key, floor jack.
5
16
Nut
1.75" spacer
Quick Jack
/ " wrench.
9
16
126
508-291-3443
.
/ " wrench and
9
16
/ "
5
16
