Factory Five Racing Mk3 Roadster Assembly Manual page 216

BOX 2A SECONDARY CHASSIS COMPONENTS (ROADSTER)
FFR # Part Name
10788 ROADSTER SECONDARY BODY FASTENERS
11061 RUBBER BUMPER, SMALL, (HOOD POST)
10701 RUBBER BUMPER, LARGE, (HOOD POST)
10983 SCREW, #8 X 3/4", (HOOD POST)
13712 FOAM WEATHERSTRIP
13841 TRUNK SEAL, RUBBER PUSH-ON TRIM
10761 ALUMINUM-BODY SEAL, RUBBER PUSH-ON TRIM
10857 WEATHERSTRIP, ADHESIVE-BACK
12129 DOOR EDGE TRIM, C-CHANNEL, (3 FT FOR EACH SIDE)
11024 BOLT, BUTTON HEAD, 5/16"-18 x 1", (BODY MOUNT)
13963 LOCK NUT, NYLON, 5/16"-18 , (BODY MOUNT)
11005 WASHER, 5/16" USS, (BODY MOUNTS)
13025 "U" NUT, 5/16"-18 , (SIDE BODY MOUNT)
14161 ¾"x ¾" PLASTIC END CAPS
14698 RIVET PACKAGE
10782 RIVETS, 1/8" SHORT
11290 RIVETS, 1/8" LONG
25799 RIVETS, 3/16" SHORT
11291 RIVETS, 3/16" LONG
12396 BATTERY RELOCATION KIT
12397 BATTERY BOX
14821 CENTER MOUNT BATTERY CROSSBAR HOLDOWN
10801 "J" BOLT, ¼"-20 x 9"
10802 LOCK NUT, NYLON, ¼"-20
11088 WASHER, ¼" USS
10973 FLEXIBLE SERRATED POLYETHYLENE GROMMETING
13931 BATTERY CABLE W/ATTACHED TERMINALS
10896 FUEL STRAP FASTENERS
11020 BOLT, ALLEN HEAD, 3/8"-16 x 2"
13964 LOCK NUT, NYLON, 3/8"-16
13977 WASHER, 3/8" SAE
11023 PEDAL BOX HARDWARE
11020 BOLT, 3/8"-16 x 2", (PEDAL BOX TO FRONT PLATE, LOWER)
10520 BOLT, 3/8"-16 x 1", (PEDAL BOX TO FRONT PLATE, UPPER)
13964 LOCK NUT, NYLON, 3/8"-16, (PEDAL BOX TO FRONT PLATE)
13977 WASHER, 3/8" SAE
12336 BOLT, SOCKET HEAD, ¼"-20 x 1.5", (PEDAL BOX TO DOWN TUBES)
12335 BOLT, ¼"-20 x 3/4", (ACC. PEDAL AND CABLE)
11088 WASHER, ¼" USS, (PEDAL BOX, ACC. PEDAL AND CABLE)
10802 LOCK NUT, NYLON, ¼"-20, (PEDAL BOX, ACC. PEDAL AND CABLE)
12337 FENDER WASHER, ¼", (PEDAL BOX TO FRAME DOWN TUBES)
10629 PEDAL SPACER, 3/16" STEEL
13806 ALUMINUM FILL PLATE
11029 INSULATED CLIP HARDWARE
10970 INSULATED CLIP, ¼"
13328 CABLE TIES, 8" LG., BAG OF 100
10971 INSULATED CLIP, 5/8"
10975 MISC. ELECTRICAL COMPONENTS
216
www.factoryfive.com 508-291-3443
Check-
Unit Qty off
EA 10.00
EA 10.00
EA 10.00
EA 1.00
FT 9.50
FT 38.00
ROL
L 1.00
FT 6.00
EA 12.00
EA 4.00
EA 36.00
EA 8.00
EA 4.00
1000.0
EA 0
EA 100.00
EA 20.00
EA 80.00
EA 1.00
EA 1.00
EA 4.00
EA 4.00
EA 4.00
FT 1.00
EA 1.00
EA 4.00
EA 4.00
EA 2.00
EA 2.00
EA 3.00
EA 5.00
EA 5.00
EA 4.00
EA 4.00
EA 8.00
EA 8.00
EA 4.00
EA 3.00
EA 1.00
EA 45.00
BAG 1.00
EA 30.00
Status
