Appendix A

WYSE 150

Set Up Mode

At any point during normal operations (i.e., PASSWORD screen, system
prompt, menu, program), you can enter the set up mode for the terminal. To
do this, hold down the Shift key and press Set Up.
There are 8 sets of values obtained by pressing the function keys F1 through
F7 and F11. Use the arrow keys to select a field. Press the Space Bar to
display the next selection for a field or Esc to call the default response. See
the default parameters below. Parameters shown in bold type can be either
response.
After making changes to the set up values, press F12 (function key 12).
Press the Space Bar to answer yes to save the changes, then press F12
again to exit.

Default Parameters

COLUMNS = 80
LINES = 24
PAGE = 1 X LINES
PERSONALITY = WYSE 50+
SCRL = JUMP
RCV CR = CR
KEYCLICK = ON
KEYLOCK = CAPS
LANGUAGE = US
BAUD RATE = 19200/9600
RCV HNDSHK = BOTH
COMM = FDX
WPRT INTENSITY = DIM
BLK END = US/CR
PRINTER ATTACHED = ON
CHAR SET = MULTINAT
CURSOR KEYS = NORMAL
FEATURE LOCK = OFF
PRINT = ASCII
SEND = ALL
XFER TERM = EOS
BAUD RATE = 19200/9600
PRINTER = SERIAL (unless otherwise specified to be parallel)
374
F1
CURSOR = BLINK BLOCK SCRN SAVER = SCRN ON
DISPLAY = DARK CHAR CELL = 10 X 16
AUTOPAGE = OFF 80/132 CLR = ON
F2
ENHANCE = OFF STATUS LINE = ON
AUTO SCRL = ON WRAP EOL = ON
MONITOR = OFF RECOGNIZE DEL = OFF
F3
REPEAT = ON KEYCODE = ASCII
MARGIN BELL = OFF BELL VOLUME = 1
CORNER KEY = FUNCT
F4
DATA/PARITY = 8/NONE STOP BITS = 1
RCV HNDSHK LEVEL = 192 XMIT HNDSHK = XON/XOFF
XMIT LIMIT = NONE HOST PORT = SERIAL 1
F5
WPRT REV = OFF WPRT UNDRLN = OFF
ATTRIBUTE = CHAR MULTIPLE PAGE = OFF
NULLS SUPRESS = ON
F6
CHAR MODE = MULTINAT ANSI ID = VT 100
KEYPAD = NUMERIC DEL = DEL/CAN
FKEY LOCK = OFF NEWLINE = OFF
F7
PRINT AREA = SCREEN PRINT TERM = NONE
SEND AREA = SCREEN SEND TERM = NONE
AUTO ANSWERBACK = OFF KEYS = TYPEWRITER
F11
DATA/PARITY = 8/NONE STOP BITS = 2/1
