For important information about how to control the projector when Input 8 is being used, see the final pages of Section 4.
4. Controlling the projector 4. Controlling the projector

Geometry menu

To return to the main menu, press
From the main menu:
• Press and until Geometry is highlighted.
Press to open the Geometry menu. The blue highlight moves to the first item
in the menu.
Input
Geometry
Colour
Setup
Information

Horizontal Position

• Press and to select H Position.
Press and to adjust the slider.

Vertical Position

• Press and to select V Position.
Press and to adjust the slider.

Aspect Ratio

• Press and to select from:
Fill This will best fit the incoming source to fill either the height or
width without changing the aspect ratio of the source.
User Aspect
1.33:1 (4:3)
1.6:1 (16:10)
1.78:1 (16:9)
2.35:1 (Scope)
1.66:1 (Vista)
1.85 (Flat)
Native The image will be displayed pixel for pixel. The image will be
centred, with a black border if smaller than native resolution or
cropped if larger.
Page 4.26 Page 4.26
Digital Projection Digital Projection
up to three times.
H Position 128
V Position
64

Aspect Ratio

User H Aspect 500
User V Aspect
500
Keystone 0
Phase 127
Resolution
Blanking
TITAN sx+ 3D, Dual 3D, Ultra Contrast TITAN sx+ 3D, Dual 3D, Ultra Contrast
1.85:1 (Flat)
User Manual User Manual
Notes
Some menu controls can be
accessed directly using the
control keys (see earlier in this
section).
When using the menus, press
OSD or
reveal the On-Screen-Display.

Geometry Menu

Some menu items may be
greyed out - unavailable due to
the effect of settings made in
other menus, or due to the type
of input signal.
Aspect Ratio selection can be
found in both the Picture and
Geometry menus.
When User Aspect is selected,
the Aspect Ratio settings are
taken from the User H Aspect
and V Aspect settings (see
next page).
Rev A August 2009 Rev A August 2009
to hide or
