For important information about how to control the projector when Input 8 is being used, see the final pages of Section 4.
4. Controlling the projector 4. Controlling the projector
Setup menu, continued
3D
• Press and to select 3D.
Press to open the 3D submenu.

3D Enable

• Press and to select 3D Enable
Press and to select from:
On
Off

Dark Time

Set the dark time to minimise any ghosting caused by the left and right images
overlapping during the time that the Z screen or 3D glasses are switching.
Fully on
Fully off
Dark
time
• Press and to select Dark Time.
Press and to adjust the slider (0 to 3000 µS).
Page 4.50 Page 4.50
Digital Projection Digital Projection
Right
Left
Dark
time
TITAN sx+ 3D, Dual 3D, Ultra Contrast TITAN sx+ 3D, Dual 3D, Ultra Contrast
Setup Menu
Dark
time
User Manual User Manual
Notes
3D
If FastFrame is turned on, then
turning 3D Enable on will turn it
off.
When 3D Enable is on, it is not
possible to turn FastFrame on.
For Input 8, 3D Enable selects
3D processing, and enables the
Dark Time, Frame Dominance
and Sync controls described on
the following pages.
For Inputs 1-7, 3D Enable also
automatically implements frame
doubling and left/right image
interleaving.
For more information about how
to set up the Dark Time and
Sync Delay controls, see the
next page.
