Control connection examples
LAN connection
All of the projector's features can be controlled via a LAN connection, using a
standard internet browser package such as Internet Explorer.
Computer
Hub or
LAN
rS232 connection
Computer
Rev A August 2009
Crossed
LAN cable
Un-crossed
LAN cables
Null-modem
cable
User Manual
Projector
Computer
Projector
Projector
Projector
2. Installation
Notes
For more information about pin
connections and control codes
see section 7. Appendix.
For more information about
using a browser to control the
projector see section 4. Using
the menus.
LAN
Wired
remote
Serial
RS232
Page 2.19
