For important information about how to control the projector when Input 8 is being used, see the final pages of Section 4.
4. Controlling the projector 4. Controlling the projector
Input menu continued

Presets

Sixteen sets of parameters can be saved and recalled (A – S). The parameters
saved for each Preset are:
all settings from the Picture menu,
all settings from the Input menu
all settings from the Geometry menu, except Keystone
all settings from the Colour menu, except the Global settings
all lens position, focus and zoom settings
• Press and to select Presets.
Press to open the Presets submenu.

recall presets

• Press and to select Recall Preset.
Press to open the Recal Presets A ~ H submenu. Any presets that have
been saved are indicated by their description, for example D: in this example.
• To recall a set of parameters that has been saved, press
one of the Presets.
For Presets J to S, select Recall Preset J ~ S then press
J~S submenu. Press
• Press to confirm your selection.
The Preset parameters will be loaded.
Page 4.20 Page 4.20
Digital Projection Digital Projection
and to select the Preset.
TITAN sx+ 3D, Dual 3D, Ultra Contrast TITAN sx+ 3D, Dual 3D, Ultra Contrast
Input Menu
Input Menu
and to select
to open the
User Manual User Manual
Notes
Some menu controls can be
accessed directly using the
control keys (see earlier in this
section).
For more information about
input modes and input presets,
see earlier in this section, Input
modes and settings.
Presets
Presets
Recall Presets A ~ H
