For important information about how to control the projector when Input 8 is being used, see the final pages of Section 4.
Digital Projection Digital Projection
TITAN sx+ 3D, Dual 3D, Ultra Contrast TITAN sx+ 3D, Dual 3D, Ultra Contrast

Screen page

To see the Screen page, click on Screen.
•

Blanking On / Off

• Click on Enable to turn the blanking On

Blanking adjust

• Use the sliders to adjust the Top, Bottom, Left and Right blanking curtains.

Keystone adjust

• Use the slider to adjust the Keystone setting.

Position adjust

• Use the sliders to adjust the Horizontal and Vertical position of the image.
Rev A August 2009 Rev A August 2009
User Manual User Manual
or Off .
5. Userware 5. Userware
Notes
The blanking curtains will not
applied until Blanking is turned
On.
For more information about
blanking, see Geometry menu,
in section 4. Controlling the
Projector.
For more information about
keystone adjustment, see
Geometry menu, in section
4. Controlling the Projector.
Page 5.13 Page 5.13
