For important information about how to control the projector when Input 8 is being used, see the final pages of Section 4.
5. Userware 5. Userware

Image page

To see the Image page, click on Image.
•

Component

• Click on Component to select one of the following from the drop down menu:
Component RGB
Component YUV
Phase
slider

Phase slider

• Use the slider to adjust the Phase.
Page 5.10 Page 5.10
Digital Projection Digital Projection
TITAN sx+ 3D, Dual 3D, Ultra Contrast TITAN sx+ 3D, Dual 3D, Ultra Contrast
The Component selection is
available for the Component
input only.
Component
For more information about
phase, see Picture menu and
Geometry menu, in section
4. Controlling the Projector.
The Phase slider is available for
RGB1 and RGB2 inputs only.
User Manual User Manual
Notes
