For important information about how to control the projector when Input 8 is being used, see the final pages of Section 4.
5. Userware 5. Userware

System page

To see the System page, click on System.
•

OSD

• Click on OSD to turn the on-screen display On

Backlight

• Click on Backlight to turn the control panel backlight On

DMD controls

• Click on the DMD buttons to turn each DMD On or Off.

Lamp mode

• Click on Lamp mode to select one of the following from the drop down menu:
Dual
Alternate
Lamp 1
Lamp 2

Lamp Power slider

• Use the slider to adjust the lamp power from 80% to 100%.
Page 5.24 Page 5.24
Digital Projection Digital Projection
TITAN sx+ 3D, Dual 3D, Ultra Contrast TITAN sx+ 3D, Dual 3D, Ultra Contrast
or Off .
or Off .
For projectors with only one
lamp, only Lamp 1 will be
available.
For more information about
lamp mode, see Setup menu,
in section 4. Controlling the
projector.
User Manual User Manual
Notes
